Water Manifold And Hoses (2.2L 16V Tc I4 Dsl 122Ps Puma) ((V) Fromca000001)

Land Rover Defender (2007-2016)

Find Your Part

Land Rover Defender (2007-2016) - Water Manifold And Hoses (2.2L 16V TC I4 DSL 122PS PUMA) ((V) FROMCA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR029965 MANIFOLD - WATER Enquire To Order
Photo Part No Description Price (each) Stock
LR004415 GASKET Enquire To Order
Photo Part No Description Price (each) Stock
LR029943 HOSE - WATER Enquire To Order
LR049202 HOSE - WATER Enquire To Order
Photo Part No Description Price (each) Stock
LR004362 CLAMP - HOSE Enquire To Order
Photo Part No Description Price (each) Stock
4558527 SCREW Enquire To Order
View All
Water Manifold And Hoses (2.2L 16V TC I4 DSL 122PS PUMA) ((V) FROMCA000001) of Land Rover Land Rover Defender (2007-2016) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 LR029965
MANIFOLD - WATER 		- 1 Enquire
2 LR004415
GASKET 		- 1 Enquire
3 LR029943
HOSE - WATER
To: DA433286 		- 1 Enquire
3 LR049202
HOSE - WATER
From: DA433287 		- 1 Enquire
4 LR004362
CLAMP - HOSE
32 x 50MM 		- 2 Enquire
5 4558527
SCREW
M6 X 20MM 		- 8 Enquire
