Switches (Steering Wheel) ((V) FROMAA000001, (V) TODA999999) of Land Rover Land Rover Discovery 4 (2010-2016) [2.7 Diesel V6]

View All

Land Rover Discovery 4 (2010-2016) [2.7 Diesel V6] - Switches (Steering Wheel) ((V) FROMAA000001, (V) TODA999999)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	QYP500050	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR022150	WIRING - STEERING WHEEL	Enquire	To Order
	LR050751	WIRING - STEERING WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR013959	SWITCH - STEERING WHEEL	Enquire	To Order
	LR022103	SWITCH - STEERING WHEEL	Enquire	To Order
	LR030352	SWITCH - STEERING WHEEL	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR013960	SWITCH - STEERING WHEEL	Enquire	To Order
	LR022104	SWITCH - STEERING WHEEL	Enquire	To Order
	LR030358	SWITCH - STEERING WHEEL	Enquire	To Order

...and 6 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR013961	SWITCH - STEERING WHEEL	Enquire	To Order
	LR017947	SWITCH - STEERING WHEEL	Enquire	To Order
	LR022105	SWITCH - STEERING WHEEL	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR013962	SWITCH - STEERING WHEEL	Enquire	To Order
	LR022106	SWITCH - STEERING WHEEL	Enquire	To Order
	LR028928	SWITCH - STEERING WHEEL	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR013963	SWITCH - STEERING WHEEL	Enquire	To Order
	LR022107	SWITCH - STEERING WHEEL	Enquire	To Order
	LR028924	SWITCH - STEERING WHEEL	Enquire	To Order

...and 8 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
HM1	QYP500050	SCREW	QYP500050 SCREW 4 x 14MM, Screw Type / From: AA000001	-	1	Enquire
13N866	LR022150	WIRING - STEERING WHEEL	LR022150 WIRING - STEERING WHEEL From: AA000001 / To: DA689762	-	1	Enquire
13N866	LR050751	WIRING - STEERING WHEEL	LR050751 WIRING - STEERING WHEEL From: DA689763	-	1	Enquire
14K147A	LR013959	SWITCH - STEERING WHEEL	LR013959 SWITCH - STEERING WHEEL Less Speed Control / LH / From: AA000001 / To: AA525399	-	1	Enquire
14K147A	LR022103	SWITCH - STEERING WHEEL	LR022103 SWITCH - STEERING WHEEL Less Speed Control / LH / From: AA525400 / To: BA579499	-	1	Enquire
14K147A	LR030352	SWITCH - STEERING WHEEL	LR030352 SWITCH - STEERING WHEEL Less Speed Control / LH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA579500 / To: DA689762	-	1	Enquire
14K147A	LR050900	SWITCH - STEERING WHEEL	LR050900 SWITCH - STEERING WHEEL Less Speed Control / LH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147B	LR013960	SWITCH - STEERING WHEEL	LR013960 SWITCH - STEERING WHEEL With Manual Speed Control / LH / From: AA000001 / To: AA525399	-	1	Enquire
14K147B	LR022104	SWITCH - STEERING WHEEL	LR022104 SWITCH - STEERING WHEEL With Manual Speed Control / LH / From: AA525400 / To: BA579499	-	1	Enquire
14K147B	LR030358	SWITCH - STEERING WHEEL	LR030358 SWITCH - STEERING WHEEL With Manual Speed Control / LH, Luxury Limited Edition, Noble / From: CA000001 / To: CA999999	-	1	Enquire
14K147B	LR030353	SWITCH - STEERING WHEEL	LR030353 SWITCH - STEERING WHEEL Leather Steering Wheel, With Manual Speed Control / LH / From: DA000001 / To: DA689762	-	1	Enquire
14K147B	LR030353	SWITCH - STEERING WHEEL	LR030353 SWITCH - STEERING WHEEL With Manual Speed Control / LH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA579500 / To: CA999999	-	1	Enquire
14K147B	LR030358	SWITCH - STEERING WHEEL	LR030358 SWITCH - STEERING WHEEL Colour Keyed Steering Wheel, With Manual Speed Control / LH, Noble / From: DA000001	-	1	Enquire
14K147B	LR041345	SWITCH - STEERING WHEEL	LR041345 SWITCH - STEERING WHEEL Steering Wheel - Gloss Black, With Manual Speed Control / LH / From: DA000001 / To: DA685999	-	1	Enquire
14K147B	LR050901	SWITCH - STEERING WHEEL	LR050901 SWITCH - STEERING WHEEL Leather Steering Wheel, With Manual Speed Control / LH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147B	LR050902	SWITCH - STEERING WHEEL	LR050902 SWITCH - STEERING WHEEL Steering Wheel - Gloss Black, With Manual Speed Control / LH / From: DA686000	-	1	Enquire
14K147C	LR013961	SWITCH - STEERING WHEEL	LR013961 SWITCH - STEERING WHEEL Leather Steering Wheel, Less Heated Steering Wheel, Less Telephone, Less Voice Input System / RH / From: AA000001 / To: AA525399	-	1	Enquire
14K147C	LR017947	SWITCH - STEERING WHEEL	LR017947 SWITCH - STEERING WHEEL Less Telephone, Less Voice Input System, With Heated Leather Steering Wheel / RH / From: AA000001 / To: AA525399	-	1	Enquire
14K147C	LR022105	SWITCH - STEERING WHEEL	LR022105 SWITCH - STEERING WHEEL Leather Steering Wheel, Less Heated Steering Wheel, Less Telephone, Less Voice Input System / RH / From: AA525400 / To: BA579499	-	1	Enquire
14K147C	LR022108	SWITCH - STEERING WHEEL	LR022108 SWITCH - STEERING WHEEL Less Telephone, Less Voice Input System, With Heated Leather Steering Wheel / RH / From: AA525400 / To: BA589499	-	1	Enquire
14K147C	LR030354	SWITCH - STEERING WHEEL	LR030354 SWITCH - STEERING WHEEL Leather Steering Wheel, Less Heated Steering Wheel, Less Telephone, Less Voice Input System / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA579500 / To: DA689762	-	1	Enquire
14K147C	LR030357	SWITCH - STEERING WHEEL	LR030357 SWITCH - STEERING WHEEL Less Telephone, Less Voice Input System, With Heated Leather Steering Wheel / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA589500 / To: DA689762	-	1	Enquire
14K147C	LR050903	SWITCH - STEERING WHEEL	LR050903 SWITCH - STEERING WHEEL Leather Steering Wheel, Less Heated Steering Wheel, Less Telephone, Less Voice Input System / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147C	LR050906	SWITCH - STEERING WHEEL	LR050906 SWITCH - STEERING WHEEL Less Telephone, Less Voice Input System, With Heated Leather Steering Wheel / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147D	LR013962	SWITCH - STEERING WHEEL	LR013962 SWITCH - STEERING WHEEL Leather Steering Wheel, Less Heated Steering Wheel, Voice Input System / RH / From: AA000001 / To: AA525399	-	1	Enquire
14K147D	LR022106	SWITCH - STEERING WHEEL	LR022106 SWITCH - STEERING WHEEL (-)"CDN/MEX/USA", Leather Steering Wheel, Less Heated Steering Wheel, Voice Input System / RH / From: AA525400 / To: BA579499	-	1	Enquire
14K147D	LR028928	SWITCH - STEERING WHEEL	LR028928 SWITCH - STEERING WHEEL (+)"CDN/MEX/USA", Leather Steering Wheel, Less Heated Steering Wheel, Less Voice Input System, With Personal Telephone Integration / RH / From: BA000001 / To: BA589499	-	1	Enquire
14K147D	LR030355	SWITCH - STEERING WHEEL	LR030355 SWITCH - STEERING WHEEL (-)"CDN/MEX/USA", Leather Steering Wheel, Less Heated Steering Wheel, Voice Input System / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA579500 / To: DA689762	-	1	Enquire
14K147D	LR032267	SWITCH - STEERING WHEEL	LR032267 SWITCH - STEERING WHEEL (+)"CDN/MEX/USA", Leather Steering Wheel, Less Heated Steering Wheel, Less Voice Input System, With Personal Telephone Integration / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA589500	-	1	Enquire
14K147D	LR040351	SWITCH - STEERING WHEEL	LR040351 SWITCH - STEERING WHEEL Less Heated Steering Wheel, Steering Wheel - Gloss Black, Voice Input System / RH / From: DA000001 / To: DA689762	-	1	Enquire
14K147D	LR050904	SWITCH - STEERING WHEEL	LR050904 SWITCH - STEERING WHEEL (-)"CDN/MEX/USA", Leather Steering Wheel, Less Heated Steering Wheel, Voice Input System / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147D	LR050907	SWITCH - STEERING WHEEL	LR050907 SWITCH - STEERING WHEEL Less Heated Steering Wheel, Steering Wheel - Gloss Black, Voice Input System / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147E	LR013963	SWITCH - STEERING WHEEL	LR013963 SWITCH - STEERING WHEEL Voice Input System, With Heated Leather Steering Wheel / RH / From: AA000001 / To: AA525399	-	1	Enquire
14K147E	LR022107	SWITCH - STEERING WHEEL	LR022107 SWITCH - STEERING WHEEL Voice Input System, With Heated Leather Steering Wheel / RH / From: AA525400 / To: BA579499	-	1	Enquire
14K147E	LR028924	SWITCH - STEERING WHEEL	LR028924 SWITCH - STEERING WHEEL With Heated Leather Steering Wheel, With Personal Telephone Integration / RH / From: BA000001 / To: BA589499	-	1	Enquire
14K147E	LR032268	SWITCH - STEERING WHEEL	LR032268 SWITCH - STEERING WHEEL With Heated Leather Steering Wheel, With Personal Telephone Integration / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA589500	-	1	Enquire
14K147E	LR030361	SWITCH - STEERING WHEEL	LR030361 SWITCH - STEERING WHEEL Colour Keyed Steering Wheel, Voice Input System, With Heated Steering Wheel / RH, Noble / From: DA000001	-	1	Enquire
14K147E	LR030361	SWITCH - STEERING WHEEL	LR030361 SWITCH - STEERING WHEEL Colour Keyed Steering Wheel, Voice Input System, With Manual Speed Control, With Personal Telephone Integration / RH, Luxury Limited Edition, Noble / From: CA000001 / To: CA999999	-	1	Enquire
14K147E	LR030356	SWITCH - STEERING WHEEL	LR030356 SWITCH - STEERING WHEEL Leather Steering Wheel, Voice Input System, With Heated Steering Wheel / RH / From: DA000001 / To: DA689762	-	1	Enquire
14K147E	LR030356	SWITCH - STEERING WHEEL	LR030356 SWITCH - STEERING WHEEL Voice Input System, With Heated Leather Steering Wheel / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: BA579500 / To: CA999999	-	1	Enquire
14K147E	LR041344	SWITCH - STEERING WHEEL	LR041344 SWITCH - STEERING WHEEL Steering Wheel - Gloss Black, Voice Input System, With Heated Steering Wheel / RH, Noble / From: DA000001 / To: DA689762	-	1	Enquire
14K147E	LR050905	SWITCH - STEERING WHEEL	LR050905 SWITCH - STEERING WHEEL Leather Steering Wheel, Voice Input System, With Heated Steering Wheel / RH, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
14K147E	LR050908	SWITCH - STEERING WHEEL	LR050908 SWITCH - STEERING WHEEL Steering Wheel - Gloss Black, Voice Input System, With Heated Steering Wheel / RH, Noble, When Used To Replace Earlier Level, Must Be Fitted In Pairs / From: DA689763	-	1	Enquire
