Land Rover Discovery Sport (2015+) [2.0 Turbo Diesel] - Fuel Lines (Under Floor) (2.0L AJ20D4 Diesel LF PTA, Halewood (UK), 2.0L AJ20D4 Diesel High PTA,...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR113126 CLIP - BRAKE PIPE Enquire To Order
Photo Part No Description Price (each) Stock
RYG500470 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
LR133032 SHIELD - FUEL TUBES Enquire To Order
Photo Part No Description Price (each) Stock
LR115336 PIPE - FUEL Enquire To Order
LR139135 PIPE - FUEL Enquire To Order
Photo Part No Description Price (each) Stock
LR115337 PIPE - FUEL Enquire To Order
Photo Part No Description Price (each) Stock
LR117831 CLIP Enquire To Order
View All
Fuel Lines (Under Floor) (2.0L AJ20D4 Diesel LF PTA, Halewood (UK), 2.0L AJ20D4 Diesel High PTA, 2.0L AJ20D4 Diesel Mid PTA) of Land Rover Land Rover Discovery Sport (2015+) [2.0 Turbo Diesel] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HC1 LR113126
CLIP - BRAKE PIPE
With Fuel Fired Heater / 4.75X8X0.8-4, Fuel Fired Heater Pipe, Single / From: LH000001 		- 5 Enquire
HS1 RYG500470
SCREW
Hexagonal Head, M10 X 25MM, Shield / From: LH000001 		- 3 Enquire
9E313 LR133032
SHIELD - FUEL TUBES
From: LH000001 		- 1 Enquire
9J280 LR115336
PIPE - FUEL
Fuel Supply And Fuel Return / From: LH000001 / To: LH854836 		- 1 Enquire
9J280 LR139135
PIPE - FUEL
Fuel Supply And Fuel Return / From: LH854837 		- 1 Enquire
9K299 LR115337
PIPE - FUEL
With Fuel Fired Heater / To Fuel Fired Heater / From: LH000001 		- 1 Enquire
9S305 LR117831
CLIP
Clip-Fuel Tube(Dual Latch) / From: LH000001 		- 3 Enquire
