Name: Front Knuckle And Hub (Disc And Caliper Size-Frt 18/RR 18, Disc And Caliper Size-Frt 19/RR 19) ((V) TOL2999999)
Rating: 4.1 (1 reviews)

Front Knuckle And Hub (Disc And Caliper Size-Frt 18/RR 18, Disc And Caliper Size-Frt 19/RR 19) ((V) TOL2999999) of Land Rover Land Rover Defender (2020+) [5.0 OHC SGDI SC V8 Petrol]

View All

Land Rover Defender (2020+) [5.0 OHC SGDI SC V8 Petrol] - Front Knuckle And Hub (Disc And Caliper Size-Frt 18/RR 18, Disc And Caliper Size-Frt 19/RR 19) ((V)...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR100039	BOLT	$5.04	To Order

Photo	Part No	Description	Price (each)	Stock
	KYG000230	BOLT	$3.08	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR042803	BOLT	$1.19	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	FY110056	NUT	$4.32	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR024151	NUT AND WASHER - HEX.	$9.59	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR043873	SCREW - PAN - TORX	$1.05	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR130427	HUB - WHEEL	$321.99	To Order
	LR142099	HUB - WHEEL	$322.00	To Order

Photo	Part No	Description	Price (each)	Stock
	LR136696	EXTENSION - FRONT KNUCKLE	$15.91	To Order
	LR136701	EXTENSION - FRONT KNUCKLE	$15.91	To Order

Photo	Part No	Description	Price (each)	Stock
	LR129159	CAP - BLEED SCREW	$3.47	To Order

Photo	Part No	Description	Price (each)	Stock
	LR137036	KNUCKLE - FRONT WHEEL	$613.56	To Order
	LR180158	KNUCKLE - FRONT WHEEL	$871.89	To Order
	LR148068	KNUCKLE - FRONT WHEEL	$613.56	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR130484	DUCT - BRAKE DISC COOLING	$25.80	To Order
	LR130487	DUCT - BRAKE DISC COOLING	$25.80	To Order
	LR141056	DUCT - BRAKE DISC COOLING	$25.04	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR130459	DUCT - BRAKE CALIPER COOLING	$35.55	To Order
	LR130458	DUCT - BRAKE CALIPER COOLING	$35.55	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
<01914	LR130459	DUCT - BRAKE CALIPER COOLING	LR130459 DUCT - BRAKE CALIPER COOLING LH	$35.55	1
<01914	LR130458	DUCT - BRAKE CALIPER COOLING	LR130458 DUCT - BRAKE CALIPER COOLING RH	$35.55	1
HB1	LR100039	BOLT	LR100039 BOLT M12 X 45MM	$5.04	8
HB2	KYG000230	BOLT IN STOCK	KYG000230 BOLT Hexagonal Head, M10 x 70MM IN STOCK	$3.08	2
HB3	LR042803	BOLT IN STOCK	LR042803 BOLT 255/60R20 113H AT, Tyre Recommend Plate-English/French / M6 x 28MM, Torx IN STOCK	$1.19	2
HN1	FY110056	NUT IN STOCK	FY110056 NUT M10 IN STOCK	$4.32	2
HN2	LR024151	NUT AND WASHER - HEX. IN STOCK	LR024151 NUT AND WASHER - HEX. M24X2.0 IN STOCK	$9.59	2
HS1	LR043873	SCREW - PAN - TORX IN STOCK	LR043873 SCREW - PAN - TORX M6 X 16MM, Torx IN STOCK	$1.05	8
2L126	LR129159	CAP - BLEED SCREW	LR129159 CAP - BLEED SCREW	$3.47	2
3K185	LR137036	KNUCKLE - FRONT WHEEL	LR137036 KNUCKLE - FRONT WHEEL RH / To: L2026300	$613.56	1
3K185	LR180158	KNUCKLE - FRONT WHEEL	LR180158 KNUCKLE - FRONT WHEEL LH / To: L2026300	$871.89	1
3K185	LR148068	KNUCKLE - FRONT WHEEL	LR148068 KNUCKLE - FRONT WHEEL RH / From: L2026301	$613.56	1
3K185	LR148066	KNUCKLE - FRONT WHEEL	LR148066 KNUCKLE - FRONT WHEEL LH / From: L2026301	$613.56	1
6K770	LR130484	DUCT - BRAKE DISC COOLING	LR130484 DUCT - BRAKE DISC COOLING RH, Disc - Brake / To: L2024675	$25.80	1
6K770	LR130487	DUCT - BRAKE DISC COOLING	LR130487 DUCT - BRAKE DISC COOLING LH, Disc - Brake / To: L2024675	$25.80	1
6K770	LR141056	DUCT - BRAKE DISC COOLING	LR141056 DUCT - BRAKE DISC COOLING RH, Disc - Brake / From: L2024676	$25.04	1
6K770	LR141059	DUCT - BRAKE DISC COOLING	LR141059 DUCT - BRAKE DISC COOLING LH, Disc - Brake / From: L2024676	$25.04	1
1104	LR130427	HUB - WHEEL	LR130427 HUB - WHEEL For NAS Please Use LR142099, RH/LH, With Bearing / To: L2001662	$321.99	2
1104	LR142099	HUB - WHEEL	LR142099 HUB - WHEEL RH/LH, With Bearing / From: L2001663	$322.00	2
02424	LR136696	EXTENSION - FRONT KNUCKLE	LR136696 EXTENSION - FRONT KNUCKLE 255/60 R20 A/S Tyre, Tyre Recommended Plate-English / RH	$15.91	1
02424	LR136701	EXTENSION - FRONT KNUCKLE	LR136701 EXTENSION - FRONT KNUCKLE 255/60R20 113H AT, Tyre Recommend Plate-English/French / LH	$15.91	1
