Switches (Steering Column) ((V) Fromaa000001)

Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC]

Find Your Part

Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC] - Switches (Steering Column) ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
XPQ500010 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
QYG500040 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
XPB500180PVJ SWITCH - STEERING COLUMN ADJUST Enquire To Order
Photo Part No Description Price (each) Stock
XPL500050 SWITCH ASSY Enquire To Order
Photo Part No Description Price (each) Stock
LR008939 SWITCH - CONTROL Enquire To Order
XPC500160 SWITCH Enquire To Order
LR029684 SWITCH - CONTROL Enquire To Order
Photo Part No Description Price (each) Stock
XPE500100 SWITCH Enquire To Order
XPE500110 SWITCH Enquire To Order
LR029691 SWITCH - CONTROL Enquire To Order
...and 1 more part variants. See table on right for more details.
View All
Switches (Steering Column) ((V) FROMAA000001) of Land Rover Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HS1 XPQ500010
SCREW
M5 X 12MM / From: AA000001 		- 4 Enquire
HS2 QYG500040
SCREW
M3 X 16MM, Switch - Multifunction (Turn/Wiper) / From: AA000001 		- 4 Enquire
11A668 XPL500050
SWITCH ASSY
Centre, Housing Assy / From: AA000001 		- 1 Enquire
14K147 LR008939
SWITCH - CONTROL
With Trip Computer / Side Turn Signal / From: AA000001 / To: AA000104 		- 1 Enquire
14K147 XPC500160
SWITCH
With Trip Computer / Side Turn Signal / From: AA000105 / To: BA999999 		- 1 Enquire
14K147 LR029684
SWITCH - CONTROL
With Trip Computer / Side Turn Signal / From: CA000001 		- 1 Enquire
17A553 XPE500100
SWITCH
Less Rain Sensor - Front W/Wiper / From: AA000001 / To: BA999999 		- 1 Enquire
17A553 XPE500110
SWITCH
Rain Sensor - Windscreen Mounted / From: AA000001 / To: BA999999 		- 1 Enquire
17A553 LR029691
SWITCH - CONTROL
Less Rain Sensor - Front W/Wiper / From: CA000001 		- 1 Enquire
17A553 LR029693
SWITCH - CONTROL
Rain Sensor - Windscreen Mounted / From: CA000001 		- 1 Enquire
14018 XPB500180PVJ
SWITCH - STEERING COLUMN ADJUST
Steering Column Adjust / From: AA000001 		- 1 Enquire
