Exhaust System

Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol]

Find Your Part

Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol] - Exhaust System

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR035750 SENSOR - LAMBDA $310.22 To Order
LR116745 SENSOR - LAMBDA $324.04 To Order
Photo Part No Description Price (each) Stock
LR035747 SENSOR - LAMBDA $325.24 To Order
LR035747 SENSOR - LAMBDA $325.24 To Order
LR140073 SENSOR - LAMBDA $246.69 To Order
...and 10 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR140077 SENSOR - EXHAUST GAS - OXYGEN $333.41 IN STOCK
LR113309 SENSOR - LAMBDA $214.11 To Order
LR035746 SENSOR - LAMBDA $286.72 To Order
...and 10 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR136928 SENSOR - LAMBDA $261.63 To Order
LR098290 SENSOR - LAMBDA $290.39 To Order
LR136928 SENSOR - LAMBDA $261.63 To Order
View All
Exhaust System of Land Rover Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
9F472A LR035750
SENSOR - LAMBDA
Exhaust Gas Oxygen, Front, RH/LH / To: JA999999 		$310.22 2
9F472A LR116745
SENSOR - LAMBDA
Exhaust Gas Oxygen, Front, RH/LH / From: KA000001 		$324.04 2
9F472B LR035747
SENSOR - LAMBDA
Less SULEV Requirements / RH, Exhaust Gas Oxygen, Middle / To: GA999999 		$325.24 1
9F472B LR035747
SENSOR - LAMBDA
EU2 / RH, Exhaust Gas Oxygen, Middle / From: HA000001 / To: HA342415 		$325.24 1
9F472B LR140073
SENSOR - LAMBDA
SULEV Requirements / RH, Exhaust Gas Oxygen, Middle / From: FA000001 / To: HA345991 		$246.69 1
9F472B LR140073
SENSOR - LAMBDA
ULEV II Requirements / RH, Exhaust Gas Oxygen, Middle / From: HA000001 / To: HA345739 		$246.69 1
9F472B LR098287
SENSOR - LAMBDA
SULEV Requirements / RH, Exhaust Gas Oxygen, Middle / From: HA345992 / To: KA999999 		$211.02 1
9F472B LR098287
SENSOR - LAMBDA
SULEV Requirements / RH, Centre, Exhaust Gas Oxygen / From: LA567000 / To: LA599999 		$211.02 1
9F472B LR098287
SENSOR - LAMBDA
SULEV Requirements / RH, Centre, Exhaust Gas Oxygen / From: LA400000 / To: LA408845 		$211.02 1
9F472B LR098287
SENSOR - LAMBDA
ULEV II Requirements / RH, Exhaust Gas Oxygen, Middle / From: HA345740 / To: HA370480 		$211.02 1
9F472B LR098291
SENSOR - EXHAUST GAS - OXYGEN
EU6 Emissions / RH, Exhaust Gas Oxygen, Middle / From: HA342416 / To: HA999999 		$316.15 1
9F472B LR098291
SENSOR - EXHAUST GAS - OXYGEN
Less SULEV Requirements / RH, Exhaust Gas Oxygen, Middle / From: JA000001 / To: JA989997 		$316.15 1
9F472B LR098291
SENSOR - EXHAUST GAS - OXYGEN
ULEV II Requirements / RH, Exhaust Gas Oxygen, Middle / From: HA370481 / To: HA999999 		$316.15 1
9F472B LR140073
SENSOR - LAMBDA
SULEV Requirements / RH, Centre, Exhaust Gas Oxygen / From: LA408846 / To: LA567000 		$246.69 1
9F472B LR140079
SENSOR - EXHAUST GAS - OXYGEN
Less SULEV Requirements / RH, Exhaust Gas Oxygen, Middle / From: JA989998 		$329.40 1
9F472C LR140077
SENSOR - EXHAUST GAS - OXYGEN
SULEV Requirements / LH, Exhaust Gas Oxygen, Middle / From: JA989999 / To: JA999999
IN STOCK 		$333.41 1
9F472C LR113309
SENSOR - LAMBDA
LH, Exhaust Gas Oxygen, Middle / From: KA000001 / To: LA598180 		$214.11 1
9F472C LR035746
SENSOR - LAMBDA
Less SULEV Requirements / LH, Exhaust Gas Oxygen, Middle / To: GA999999 		$286.72 1
9F472C LR035746
SENSOR - LAMBDA
Proconve L6 Emissions / LH, Exhaust Gas Oxygen, Middle / From: HA000001 / To: HA343167 		$286.72 1
9F472C LR140078
SENSOR - EXHAUST GAS - OXYGEN
Less SULEV Requirements / LH, Exhaust Gas Oxygen, Middle / From: JA398556 / To: JA999999 		$329.40 1
9F472C LR140077
SENSOR - EXHAUST GAS - OXYGEN
SULEV Requirements / LH, Exhaust Gas Oxygen, Middle / From: FA000001 / To: HA343439
IN STOCK 		$333.41 1
9F472C LR140077
SENSOR - EXHAUST GAS - OXYGEN
ULEV II Requirements / LH, Exhaust Gas Oxygen, Middle / From: HA000001 / To: HA343163
IN STOCK 		$333.41 1
9F472C LR098293
SENSOR - LAMBDA
SULEV Requirements / LH, Exhaust Gas Oxygen, Middle / From: HA343440 / To: JA989998 		$261.63 1
9F472C LR098293
SENSOR - LAMBDA
ULEV II Requirements / LH, Exhaust Gas Oxygen, Middle / From: HA343164 / To: HA370480 		$261.63 1
9F472C LR098285
SENSOR - LAMBDA
Proconve L6 Emissions / LH, Exhaust Gas Oxygen, Middle / From: HA343168 / To: HA999999 		$318.26 1
9F472C LR098285
SENSOR - LAMBDA
Less SULEV Requirements / LH, Exhaust Gas Oxygen, Middle / From: JA000001 / To: JA398555 		$318.26 1
9F472C LR098285
SENSOR - LAMBDA
ULEV II Requirements / LH, Exhaust Gas Oxygen, Middle / From: HA370481 / To: HA999999 		$318.26 1
9F472C LR140082
SENSOR - LAMBDA
LH, Exhaust Gas Oxygen, Middle / From: LA598181 		$275.25 1
9F472D LR136928
SENSOR - LAMBDA
Exhaust Gas Oxygen, Rear, RH/LH / To: HA343439 		$261.63 2
9F472D LR098290
SENSOR - LAMBDA
Exhaust Gas Oxygen, Rear, RH/LH / From: HA343440 / To: LA892680 		$290.39 2
9F472D LR136928
SENSOR - LAMBDA
Exhaust Gas Oxygen, Rear, RH/LH / From: LA892681 		$261.63 2
