Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC] - Rear Springs And Shock Absorbers ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR014904 CLIP - WIRING ( NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR015001 CLIP Enquire To Order
Photo Part No Description Price (each) Stock
FY114047 NUT (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
FY110056 NUT Enquire To Order
Photo Part No Description Price (each) Stock
RNS000041 PLATE (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR015002 WASHER (NON HAZ) Enquire To Order
RNS500010 WASHER - DAMPER LOCKING (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR014955 SPACER Enquire To Order
Photo Part No Description Price (each) Stock
LR018170 SPRING (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR016411 SPRING (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR015407 SPRING (NON HAZ) Enquire To Order
RPM500200 BOOT (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
RPC500030 DAMPER (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR018192 KIT - ELECTRICAL PARTS ( NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR018171 KIT - DAMPER SEALS (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR016412 KIT (NON HAZ) Enquire To Order
Photo Part No Description Price (each) Stock
LR015018 SHOCK ABSORBER Enquire To Order
LR015020 SHOCK ABSORBER Enquire To Order
LR020000 SHOCK ABSORBER Enquire To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR016420 DAMPER (NON HAZ) Enquire To Order
LR016419 SHOCK ABSORBER (NON HAZ) Enquire To Order
LR016418 DAMPER Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR015405 DAMPER Enquire To Order
LR016164 KIT - SHOCK ABSORBER Enquire To Order
LR023431 KIT - SHOCK ABSORBER Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR016425 DAMPER (NON HAZ) Enquire To Order
LR016424 DAMPER (NON HAZ) Enquire To Order
LR016423 DAMPER (NON HAZ) Enquire To Order
View All
Rear Springs And Shock Absorbers ((V) FROMAA000001) of Land Rover Land Rover Range Rover Sport (2010-2013) [3.0 Diesel 24V DOHC TC] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HC1 LR014904
CLIP - WIRING ( NON HAZ)
With Continuous Variable Damping / Connector / From: AA000001 		- 2 Enquire
HC2 LR015001
CLIP
With Continuous Variable Damping / Shock Absorber / From: AA000001 		- 2 Enquire
HN1 FY114047
NUT (NON HAZ)
Flanged, Locking, M14 / From: AA000001 		- 2 Enquire
HN2 FY110056
NUT
M10 / From: AA000001 		- 6 Enquire
HW1 RNS000041
PLATE (NON HAZ)
Bump Washer / From: AA000001 		- 2 Enquire
HW2 LR015002
WASHER (NON HAZ)
With Continuous Variable Damping / Shock Absorber / From: AA000001 		- 2 Enquire
HW2 RNS500010
WASHER - DAMPER LOCKING (NON HAZ)
Less Adaptive Damping / 		- 2 Enquire
HW3 LR014955
SPACER
With Continuous Variable Damping / Shock Absorber / From: AA000001 		- 2 Enquire
5A669A LR015018
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: AA000001 / To: AA216111 		- 1 Enquire
5A669A LR015020
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: AA000001 / To: AA216111 		- 1 Enquire
5A669A LR020000
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: AA216112 / To: AA243562 		- 1 Enquire
5A669A LR020001
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: AA216112 / To: AA243562 		- 1 Enquire
5A669A LR023234
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: AA243563 / To: CA726369 		- 1 Enquire
5A669A LR023235
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: AA243563 / To: CA726369 		- 1 Enquire
5A669A LR032651
SHOCK ABSORBER
With Continuous Variable Damping / LH, Complete Module Assy / From: CA726370 		- 1 Enquire
5A669A LR032652
SHOCK ABSORBER
With Continuous Variable Damping / RH, Complete Module Assy / From: CA726370 		- 1 Enquire
5A669B LR016420
DAMPER (NON HAZ)
3.6L V8 32V DOHC EFi Diesel Lion, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Complete Module Assy / From: AA000001 / To: AA999999 		- 2 Enquire
5A669B LR016419
SHOCK ABSORBER (NON HAZ)
3.0L 24V DOHC V6 TC Diesel, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Complete Module Assy / From: AA000001 		- 2 Enquire
5A669B LR016418
DAMPER
Less ACE Suspension, Less Adaptive Damping, Less Roll Stability Control / Complete Module Assy / From: AA000001 / To: CA758725 		- 2 Enquire
5A669B LR041110
MACPHERSON STRUT
Less ACE Suspension, Less Adaptive Damping, Less Roll Stability Control / Complete Module Assy / From: CA758726 		- 2 Enquire
5A669C LR015405
DAMPER
With Continuous Variable Damping / RH, Service Kit / From: AA000001 / To: AA247351 		- 1 Enquire
5A669C LR016164
KIT - SHOCK ABSORBER
With Continuous Variable Damping / LH, Service Kit / From: AA000001 / To: AA247351 		- 1 Enquire
5A669C LR023431
KIT - SHOCK ABSORBER
With Continuous Variable Damping / LH, Service Kit / From: AA247352 		- 1 Enquire
5A669C LR023436
DAMPER
With Continuous Variable Damping / RH, Service Kit / From: AA247352 		- 1 Enquire
5A669D LR016425
DAMPER (NON HAZ)
3.6L V8 32V DOHC EFi Diesel Lion, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Includes Seal, Service Kit / From: AA000001 / To: AA999999 		- 2 Enquire
5A669D LR016424
DAMPER (NON HAZ)
3.0L 24V DOHC V6 TC Diesel, Less Adaptive Damping, With ACE Suspension, With Roll Stability Control / Includes Seal, Service Kit / From: AA000001 		- 2 Enquire
5A669D LR016423
DAMPER (NON HAZ)
Less ACE Suspension, Less Adaptive Damping, Less Roll Stability Control / Includes Seal, Service Kit / From: AA000001 		- 2 Enquire
5B752 LR015407
SPRING (NON HAZ)
With Continuous Variable Damping / From: AA000001 		- 2 Enquire
5B752 RPM500200
BOOT (NON HAZ)
Less Adaptive Damping / From: AA000001 		- 2 Enquire
5K502 RPC500030
DAMPER (NON HAZ)
From: AA000001 		- 2 Enquire
14N424 LR018192
KIT - ELECTRICAL PARTS ( NON HAZ)
With Continuous Variable Damping / From: AA000001 		- 2 Enquire
5560A LR018170
SPRING (NON HAZ)
With Continuous Variable Damping / Service Kit / From: AA000001 		- 2 Enquire
5560B LR016411
SPRING (NON HAZ)
Less Adaptive Damping / Service Kit / From: AA000001 		- 2 Enquire
58702A LR018171
KIT - DAMPER SEALS (NON HAZ)
With Continuous Variable Damping / Includes O-Rings, Spacers And A Nut / From: AA000001 		- 2 Enquire
58702B LR016412
KIT (NON HAZ)
Less Adaptive Damping / Includes O-Rings, Spacers And A Nut / From: AA000001 		- 2 Enquire
