Land Rover Range Rover Sport (2014+) [2.0 Turbo Diesel] - Turbocharger (Lubrication And Cooling, Solihull Plant Build) (2.0L I4 DSL HIGH DOHC AJ200) ((V)...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR073687 O-RING Enquire To Order
Photo Part No Description Price (each) Stock
LR073688 O-RING Enquire To Order
Photo Part No Description Price (each) Stock
LR073686 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
LR073671 WASHER - COPPER Enquire To Order
Photo Part No Description Price (each) Stock
LR081630 HOSE - OIL RETURN Enquire To Order
LR110749 HOSE - OIL RETURN Enquire To Order
Photo Part No Description Price (each) Stock
LR081635 PIPE - OIL DRAIN Enquire To Order
Photo Part No Description Price (each) Stock
LR081637 PIPE - OIL DRAIN Enquire To Order
Photo Part No Description Price (each) Stock
LR081638 PIPE - OIL DRAIN Enquire To Order
Photo Part No Description Price (each) Stock
LR081639 PIPE - OIL DRAIN Enquire To Order
Photo Part No Description Price (each) Stock
LR081653 HOSE - WATER OUTLET Enquire To Order
Photo Part No Description Price (each) Stock
LR081654 HOSE - WATER INLET Enquire To Order
View All
Turbocharger (Lubrication And Cooling, Solihull Plant Build) (2.0L I4 DSL HIGH DOHC AJ200) ((V) FROMHA000001) of Land Rover Land Rover Range Rover Sport (2014+) [2.0 Turbo Diesel] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HR1 LR073687
O-RING
14.3 x 2.4, Turbocharger To Pipe / From: HA000001 		- 2 Enquire
HR2 LR073688
O-RING
15 X 3MM, Lower / From: HA000001 		- 3 Enquire
HS1 LR073686
SCREW
M6 X 16MM / From: HA000001 		- 3 Enquire
6K677A LR081630
HOSE - OIL RETURN
Lower / From: HA000001 / To: HA695218 		- 1 Enquire
6K677A LR110749
HOSE - OIL RETURN
Lower / From: HA695219 		- 1 Enquire
6K677B LR081635
PIPE - OIL DRAIN
Turbocharger, Upper / From: HA000001 		- 1 Enquire
6K677C LR081637
PIPE - OIL DRAIN
Cylinder Block, Upper / From: HA000001 		- 1 Enquire
6K679A LR081638
PIPE - OIL DRAIN
Secondary / From: HA000001 		- 1 Enquire
6K679B LR081639
PIPE - OIL DRAIN
Primary / From: HA000001 		- 1 Enquire
6K683A LR081653
HOSE - WATER OUTLET
Cylinder Block, Hose Water Outlet From Turbocharger / From: HA000001 		- 1 Enquire
6K683B LR081654
HOSE - WATER INLET
Hose Water Inlet To Turbocharger / From: HA000001 		- 1 Enquire
9450 LR073671
WASHER - COPPER
Banjo Washer, Requires 2 Pcs Per Banjo-Bolt, Turbocharger Oil Feed / From: HA000001 		- 8 Enquire
