Front Door Lock Controls (Changsu (China)) ((V) FROMFG000001) of Land Rover Land Rover Discovery Sport (2015+) [2.0 Turbo Petrol AJ200P]

View All

Land Rover Discovery Sport (2015+) [2.0 Turbo Petrol AJ200P] - Front Door Lock Controls (Changsu (China)) ((V) FROMFG000001)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR038526	BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR000804	PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR058114	PLUG - BLANKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	RYP500700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR042467	BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR059989	PLUG - BLANKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR063627	LATCH - FRONT DOOR	Enquire	To Order
	LR063610	LATCH - FRONT DOOR	Enquire	To Order
	LR070436	LATCH - FRONT DOOR	Enquire	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR059010	STRIKER - DOOR LOCKING MECHANISM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR061200	HANDLE - DOOR - OUTER	Enquire	To Order
	LR061201	HANDLE - DOOR - OUTER	Enquire	To Order
	LR055913	HANDLE - DOOR - OUTER	Enquire	To Order

...and 17 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR034461	GASKET - DOOR HANDLE	Enquire	To Order
	LR087704	GASKET - DOOR HANDLE	Enquire	To Order
	LR117080	GASKET - DOOR HANDLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR025406	CAP - HANDLE	Enquire	To Order
	LR038477	CAP - HANDLE	Enquire	To Order
	LR055902	CAP - HANDLE	Enquire	To Order

...and 23 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR070989	REINFORCEMENT - DOOR HANDLE	Enquire	To Order
	LR070993	REINFORCEMENT - DOOR HANDLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR070994	BRACKET - DOOR HANDLE MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR070988	BRACKET - DOOR HANDLE MOUNTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR058115	COVER - LATCH	Enquire	To Order
	LR058117	COVER - LATCH	Enquire	To Order
	LR070443	COVER - LATCH	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR058116	COVER - LATCH	Enquire	To Order
	LR058118	COVER - LATCH	Enquire	To Order
	LR070444	COVER - LATCH	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR060922	CABLE - DOOR LATCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR059991	CABLE - DOOR LATCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR059990	CABLE - DOOR LATCH	Enquire	To Order
	LR127326	CABLE - DOOR LATCH	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
<218A14	LR025406	CAP - HANDLE	LR025406 CAP - HANDLE Body Coloured Exterior Door Handle / Less Lock Barrel Aperture, Primed / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR038477	CAP - HANDLE	LR038477 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Polaris White/Fuji White (1AA) / For Passengers Side / From: FG000001 / To: GG343240	-	1	Enquire
<218A14	LR055902	CAP - HANDLE	LR055902 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Quartzite/Kaikoura Stone (1AP) / For Passengers Side / From: FG000001 / To: HG379387	-	1	Enquire
<218A14	LR038481	CAP - HANDLE	LR038481 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Firenze Red (868) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR053338	CAP - HANDLE	LR053338 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Zanzibar (872) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR046310	CAP - HANDLE	LR046310 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Scotia Grey (943) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR038475	CAP - HANDLE	LR038475 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Corris Grey (873) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR069725	CAP - HANDLE	LR069725 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Yulong White (2201) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR053340	CAP - HANDLE	LR053340 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Mauritius Blue (864) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR038486	CAP - HANDLE	LR038486 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Santorini Black (820) / For Passengers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR048299	CAP - DOOR LOCKING MECHANISM	LR048299 CAP - DOOR LOCKING MECHANISM Body Coloured Exterior Door Handle / Primed, With Lock Barrel Aperture / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR054972	CAP - HANDLE	LR054972 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Scotia Grey (943) / For Drivers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR054964	CAP - HANDLE	LR054964 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Polaris White/Fuji White (1AA) / For Drivers Side, With Lock Barrel Aperture / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR054974	CAP - HANDLE	LR054974 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Santorini Black (820) / For Drivers Side / From: JG418566 / To: KG446856	-	1	Enquire
<218A14	LR055897	CAP - DOOR LOCKING MECHANISM	LR055897 CAP - DOOR LOCKING MECHANISM Body Coloured/Noble Ext Door Handle, Kaikoura Stone (997) / For Drivers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR070086	CAP - HANDLE	LR070086 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Yulong White (2201) / For Drivers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR054969	CAP - HANDLE	LR054969 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Firenze Red (868) / For Drivers Side / From: HG357181 / To: KG446856	-	1	Enquire
<218A14	LR054961	CAP - HANDLE	LR054961 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Corris Grey (873) / For Drivers Side / From: FG000001 / To: KG446856	-	1	Enquire
<218A14	LR053341	CAP - HANDLE	LR053341 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Zanzibar (872) / For Drivers Side / From: HG390235 / To: KG446856	-	1	Enquire
<218A14	LR046252	CAP - HANDLE	LR046252 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Dark Sapphire Blue/Loire Blue (1AM) / For Passengers Side / From: GG343240 / To: KG446856	-	1	Enquire
<218A14	LR054970	CAP - HANDLE	LR054970 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Dark Sapphire Blue/Loire Blue (1AM) / With Lock Barrel Aperture / From: HG347884 / To: KG446856	-	1	Enquire
<218A14	LR106323	CAP - HANDLE	LR106323 CAP - HANDLE Body Coloured/Noble Ext Door Handle / Primed, With Lock Barrel Aperture / From: HG379388 / To: KG446856	-	1	Enquire
<218A14	LR038477	CAP - HANDLE	LR038477 CAP - HANDLE Body Coloured/Noble Ext Door Handle, Fuji White (867) / Less Lock Barrel Aperture / From: GG343240 / To: KG446856	-	1	Enquire
<218A14	LR156944	CAP - DOOR LOCKING MECHANISM	LR156944 CAP - DOOR LOCKING MECHANISM Primed, With Lock Barrel Aperture / From: MG140569	-	1	Enquire
<218A14	LR025406	CAP - HANDLE	LR025406 CAP - HANDLE Less Lock Barrel Aperture, Primed / From: KG446857	-	1	Enquire
<218A14	LR048299	CAP - DOOR LOCKING MECHANISM	LR048299 CAP - DOOR LOCKING MECHANISM Primed, With Lock Barrel Aperture / From: KG446857 / To: MG140568	-	1	Enquire
<224N02	LR070989	REINFORCEMENT - DOOR HANDLE	LR070989 REINFORCEMENT - DOOR HANDLE For Passengers Side / From: FG000001	-	1	Enquire
<224N02	LR070993	REINFORCEMENT - DOOR HANDLE	LR070993 REINFORCEMENT - DOOR HANDLE Double Locking Power Lock Latch / For Drivers Side / From: FG000001	-	1	Enquire
<226A20A	LR070994	BRACKET - DOOR HANDLE MOUNTING	LR070994 BRACKET - DOOR HANDLE MOUNTING LH, For Drivers Side / From: FG000001	-	1	Enquire
<226A20B	LR070988	BRACKET - DOOR HANDLE MOUNTING	LR070988 BRACKET - DOOR HANDLE MOUNTING Passenger Side, RH/LH / From: FG000001	-	1	Enquire
<431B38A	LR058115	COVER - LATCH	LR058115 COVER - LATCH Keyless Entry/Start - Passive / RH, Upper / From: FG000001 / To: MG140568	-	1	Enquire
<431B38A	LR058117	COVER - LATCH	LR058117 COVER - LATCH Keyless Entry/Start - Passive / LH, Upper / From: FG000001 / To: MG140568	-	1	Enquire
<431B38A	LR070443	COVER - LATCH	LR070443 COVER - LATCH With Keyless Start / RH, Upper / From: FG000001 / To: MG140568	-	1	Enquire
<431B38A	LR070459	COVER - LATCH	LR070459 COVER - LATCH With Keyless Start / LH, Upper / From: FG000001 / To: MG140568	-	1	Enquire
<431B38B	LR058116	COVER - LATCH	LR058116 COVER - LATCH Keyless Entry/Start - Passive / RH, Lower / From: FG000001 / To: MG140568	-	1	Enquire
<431B38B	LR058118	COVER - LATCH	LR058118 COVER - LATCH Keyless Entry/Start - Passive / LH, Lower / From: FG000001 / To: MG140568	-	1	Enquire
<431B38B	LR070444	COVER - LATCH	LR070444 COVER - LATCH With Keyless Start / RH, Lower / From: FG000001 / To: MG140568	-	1	Enquire
<431B38B	LR070460	COVER - LATCH	LR070460 COVER - LATCH With Keyless Start / LH, Lower / From: FG000001 / To: MG140568	-	1	Enquire
<431C22A	LR060922	CABLE - DOOR LATCH	LR060922 CABLE - DOOR LATCH For Drivers Side, Lock Cylinder To Latch / From: FG000001	-	1	Enquire
<431C22B	LR059991	CABLE - DOOR LATCH	LR059991 CABLE - DOOR LATCH Outside Door Release Handle To Latch, RH/LH / From: FG000001	-	1	Enquire
<431C22C	LR059990	CABLE - DOOR LATCH	LR059990 CABLE - DOOR LATCH Door Release Control, Internal, RH/LH / From: FG000001 / To: KG446856	-	1	Enquire
<431C22C	LR127326	CABLE - DOOR LATCH	LR127326 CABLE - DOOR LATCH Door Release Control, Internal, RH/LH / From: KG446857	-	1	Enquire
<21812	LR063627	LATCH - FRONT DOOR	LR063627 LATCH - FRONT DOOR Keyless Entry/Start - Passive / RH / From: FG000001 / To: HG379388	-	1	Enquire
<21812	LR063610	LATCH - FRONT DOOR	LR063610 LATCH - FRONT DOOR Keyless Entry/Start - Passive / LH / From: FG000001 / To: HG379388	-	1	Enquire
<21812	LR070436	LATCH - FRONT DOOR	LR070436 LATCH - FRONT DOOR With Keyless Start / RH / From: FG000001	-	1	Enquire
<21812	LR070438	LATCH - FRONT DOOR	LR070438 LATCH - FRONT DOOR With Keyless Start / LH / From: FG000001	-	1	Enquire
<21812	LR078707	LATCH - FRONT DOOR	LR078707 LATCH - FRONT DOOR Keyless Entry/Start - Passive / RH / From: HG379389	-	1	Enquire
<21812	LR078730	LATCH - FRONT DOOR	LR078730 LATCH - FRONT DOOR Keyless Entry/Start - Passive / LH / From: HG379389	-	1	Enquire
<21982	LR059010	STRIKER - DOOR LOCKING MECHANISM	LR059010 STRIKER - DOOR LOCKING MECHANISM RH/LH / From: FG000001	-	2	Enquire
<22404	LR061200	HANDLE - DOOR - OUTER	LR061200 HANDLE - DOOR - OUTER Body Coloured Exterior Door Handle, Keyless Entry/Start - Passive / Primed, RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR061201	HANDLE - DOOR - OUTER	LR061201 HANDLE - DOOR - OUTER Body Coloured Exterior Door Handle, With Keyless Start / Primed, RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR055913	HANDLE - DOOR - OUTER	LR055913 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Kaikoura Stone (997), Keyless Entry/Start - Passive / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR055914	HANDLE - DOOR - OUTER	LR055914 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Firenze Red (868), Keyless Entry/Start - Passive / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR046327	HANDLE - DOOR - OUTER	LR046327 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive, Scotia Grey (943) / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR056188	HANDLE - DOOR - OUTER	LR056188 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Corris Grey (873), Keyless Entry/Start - Passive / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR072371	HANDLE - DOOR - OUTER	LR072371 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive, Yulong White (2201) / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR056232	HANDLE - DOOR - OUTER	LR056232 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive, Zanzibar (872) / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR056233	HANDLE - DOOR - OUTER	LR056233 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive, Mauritius Blue (864) / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR055921	HANDLE - DOOR - OUTER	LR055921 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive, Polaris White/Fuji White (1AA) / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR055916	HANDLE - DOOR - OUTER	LR055916 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive, Santorini Black (820) / RH/LH / From: FG000001 / To: MG140568	-	2	Enquire
<22404	LR046326	HANDLE - DOOR - OUTER	LR046326 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Dark Sapphire Blue/Loire Blue (1AM), Keyless Entry/Start - Passive / RH/LH / From: GG343240 / To: MG140568	-	2	Enquire
<22404	LR106320	HANDLE - DOOR - OUTER	LR106320 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, Keyless Entry/Start - Passive / Primed, RH/LH / From: HG379388 / To: MG140568	-	1	Enquire
<22404	LR106321	HANDLE - DOOR - OUTER	LR106321 HANDLE - DOOR - OUTER Body Coloured/Noble Ext Door Handle, With Keyless Start / Primed, RH/LH / From: HG379388 / To: MG140568	-	1	Enquire
<22404	LR098256	HANDLE - DOOR - OUTER	LR098256 HANDLE - DOOR - OUTER Keyless Entry/Start - Passive, Sunstone Copper/Zanzibar (1BH) / Primed, RH/LH / From: KG446857	-	2	Enquire
<22404	LR112362	HANDLE - DOOR - OUTER	LR112362 HANDLE - DOOR - OUTER Gallium/Silicon Silver (1BN), Keyless Entry/Start - Passive / RH/LH / From: LG124185	-	4	Enquire
<22404	LR112353	HANDLE - DOOR - OUTER	LR112353 HANDLE - DOOR - OUTER Keyless Entry/Start - Passive, Polaris White/Fuji White (1AA) / RH/LH, White / From: MG140569	-	4	Enquire
<22404	LR112356	HANDLE - DOOR - OUTER	LR112356 HANDLE - DOOR - OUTER Italian Racing Red/Firenze Red(1AF), Keyless Entry/Start - Passive / RH/LH / From: MG140569	-	4	Enquire
<22404	LR112361	HANDLE - DOOR - OUTER	LR112361 HANDLE - DOOR - OUTER Flores Blue/Byron Blue (1CK), Keyless Entry/Start - Passive / RH/LH / From: MG140569	-	4	Enquire
<22404	LR112363	HANDLE - DOOR - OUTER	LR112363 HANDLE - DOOR - OUTER Keyless Entry/Start - Passive, Ultimate Black/Santorini Black(1AG) / RH/LH / From: MG140569	-	4	Enquire
<22444	LR034461	GASKET - DOOR HANDLE	LR034461 GASKET - DOOR HANDLE RH/LH / From: FG000001 / To: HG347883	-	2	Enquire
<22444	LR087704	GASKET - DOOR HANDLE	LR087704 GASKET - DOOR HANDLE RH/LH / From: HG347884 / To: KG425225	-	4	Enquire
<22444	LR117080	GASKET - DOOR HANDLE	LR117080 GASKET - DOOR HANDLE RH/LH / From: KG425226	-	1	Enquire
HB1	LR038526	BOLT	LR038526 BOLT M6 X 11MM / From: FG000001	-	1	Enquire
HP1	LR000804	PLUG	LR000804 PLUG 10 X 0.75 X 1.0 / From: FG000001	-	4	Enquire
HP2	LR058114	PLUG - BLANKING	LR058114 PLUG - BLANKING Seal / From: FG000001	-	1	Enquire
HS1	RYP500700	SCREW	RYP500700 SCREW M5 X 12MM, Torx / From: FG000001	-	1	Enquire
HS2	LR042467	BOLT	LR042467 BOLT M8 X 25MM / From: FG000001	-	2	Enquire
7A010	LR059989	PLUG - BLANKING	LR059989 PLUG - BLANKING RH/LH / From: FG000001	-	2	Enquire
