Name: Rear Springs And Shock Absorbers (Version - Core, With Four Corner Air Suspension, Non SVR, Electronic Air Suspension With ACE)
Rating: 5.0 (1 reviews)

Rear Springs And Shock Absorbers (Version - Core, With Four Corner Air Suspension, Non SVR, Electronic Air Suspension With ACE) of Land Rover Land Rover Range Rover Sport (2014+) [2.0 Turbo Petrol GTDI]

View All

Land Rover Range Rover Sport (2014+) [2.0 Turbo Petrol GTDI] - Rear Springs And Shock Absorbers (Version - Core, With Four Corner Air Suspension, Non SVR,...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR038196	BOLT	$10.29	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	RYC500220	CLIP	$15.98	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR044836	CONNECTOR - VALVE BLOCK TO PIPE	$23.10	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR034278	NUT	$4.78	To Order
	LR116654	NUT	$6.58	To Order

Photo	Part No	Description	Price (each)	Stock
	LR034227	NUT - FLANGED	$6.09	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR034277	NUT	$3.65	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR041901	KIT - BOOT	$10.79	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR044853	SPRING - AIR SUSPENSION (NON HAZ)	$720.58	To Order
	LR052171	SPRING - AIR SUSPENSION	$720.58	To Order

Photo	Part No	Description	Price (each)	Stock
	LR047321	BUMPER - SHOCK ABSORBER	$30.80	To Order

Photo	Part No	Description	Price (each)	Stock
	LR034276	SEAL - STRUT TOP	$3.86	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR034244	REINFORCEMENT - SUSPENSION BRACKET	$118.78	To Order

Photo	Part No	Description	Price (each)	Stock
	LR100873	SHOCK ABSORBER - REAR	$1,431.10	To Order
	LR045269	SHOCK ABSORBER	$677.25	To Order
	LR045269	SHOCK ABSORBER	$677.25	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR047322	SHOCK ABSORBER	$444.47	To Order
	LR047322	SHOCK ABSORBER	$444.47	To Order
	LR047323	SHOCK ABSORBER - REAR	$888.94	To Order

...and 5 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR038196	BOLT IN STOCK	LR038196 BOLT HEX Flange, Hexagonal Head, M14 X 125 IN STOCK	$10.29	2
HC1	RYC500220	CLIP IN STOCK	RYC500220 CLIP Air Spring IN STOCK	$15.98	2
HM1	LR044836	CONNECTOR - VALVE BLOCK TO PIPE IN STOCK	LR044836 CONNECTOR - VALVE BLOCK TO PIPE 6MM, Air Tube Connector IN STOCK	$23.10	2
HN1	LR034278	NUT	LR034278 NUT With Continuous Variable Damping / M12 x 1	$4.78	2
HN1	LR116654	NUT	LR116654 NUT Less Adaptive Damping / M12 x 1.5	$6.58	2
HN2	LR034227	NUT - FLANGED IN STOCK	LR034227 NUT - FLANGED M10 IN STOCK	$6.09	6
HN3	LR034277	NUT IN STOCK	LR034277 NUT M14, Nut And Washer IN STOCK	$3.65	2
4L537	LR041901	KIT - BOOT IN STOCK	LR041901 KIT - BOOT Includes Boot And Clip IN STOCK	$10.79	2
5A980	LR044853	SPRING - AIR SUSPENSION (NON HAZ)	LR044853 SPRING - AIR SUSPENSION (NON HAZ) RH	$720.58	1
5A980	LR052171	SPRING - AIR SUSPENSION	LR052171 SPRING - AIR SUSPENSION LH	$720.58	1
5K570	LR047321	BUMPER - SHOCK ABSORBER	LR047321 BUMPER - SHOCK ABSORBER RH/LH, Shock Absorber	$30.80	2
7H424	LR034276	SEAL - STRUT TOP IN STOCK	LR034276 SEAL - STRUT TOP Antisqueak, RH/LH IN STOCK	$3.86	2
101A14	LR034244	REINFORCEMENT - SUSPENSION BRACKET	LR034244 REINFORCEMENT - SUSPENSION BRACKET RH/LH, Shock Absorber	$118.78	2
18125A	LR100873	SHOCK ABSORBER - REAR	LR100873 SHOCK ABSORBER - REAR Electric Engine Battery-PHEV / RH/LH, With Reinforcement, Seal And Nut / From: JA000001	$1,431.10	2
18125A	LR045269	SHOCK ABSORBER	LR045269 SHOCK ABSORBER Less Adaptive Damping / RH/LH, With Reinforcement, Seal And Nut / To: HA999999	$677.25	2
18125A	LR045269	SHOCK ABSORBER	LR045269 SHOCK ABSORBER Less Adaptive Damping, Less Electric Engine Battery / RH/LH, With Reinforcement, Seal And Nut / From: JA000001	$677.25	2
18125A	LR045270	SHOCK ABSORBER	LR045270 SHOCK ABSORBER With ACE Suspension, With Continuous Variable Damping / RH/LH, With Reinforcement, Seal And Nut / To: HA999999	$925.60	2
18125A	LR045270	SHOCK ABSORBER	LR045270 SHOCK ABSORBER Electric Engine Battery-MHEV, Electronic Air Suspension With ACE, With Continuous Variable Damping / RH/LH, With Reinforcement, Seal And Nut / From: JA000001	$925.60	2
18125A	LR047132	SHOCK ABSORBER	LR047132 SHOCK ABSORBER Less ACE Suspension, With Continuous Variable Damping / RH/LH, With Reinforcement, Seal And Nut / To: HA999999	$925.60	2
18125A	LR047132	SHOCK ABSORBER	LR047132 SHOCK ABSORBER Less Electric Engine Battery, With Continuous Variable Damping, With Four Corner Air Suspension / RH/LH, With Reinforcement, Seal And Nut / From: JA000001	$925.60	2
18125A	LR047132	SHOCK ABSORBER	LR047132 SHOCK ABSORBER Electric Engine Battery-MHEV, With Continuous Variable Damping, With Four Corner Air Suspension / RH/LH, With Reinforcement, Seal And Nut / From: KA000001	$925.60	2
18125B	LR047322	SHOCK ABSORBER	LR047322 SHOCK ABSORBER Less Adaptive Damping / Less Reinforcement, Seal And Nut, RH/LH / To: HA999999	$444.47	2
18125B	LR047322	SHOCK ABSORBER	LR047322 SHOCK ABSORBER Less Adaptive Damping, Less Electric Engine Battery / Less Reinforcement, Seal And Nut, RH/LH / From: JA000001	$444.47	2
18125B	LR047323	SHOCK ABSORBER - REAR	LR047323 SHOCK ABSORBER - REAR With ACE Suspension, With Continuous Variable Damping / Less Reinforcement, Seal And Nut, RH/LH / To: HA999999	$888.94	2
18125B	LR047323	SHOCK ABSORBER - REAR	LR047323 SHOCK ABSORBER - REAR Electric Engine Battery-MHEV, Electronic Air Suspension With ACE, With Continuous Variable Damping / Less Reinforcement, Seal And Nut, RH/LH / From: JA000001	$888.94	2
18125B	LR105979	SHOCK ABSORBER	LR105979 SHOCK ABSORBER Electric Engine Battery-PHEV / Less Reinforcement, Seal And Nut, RH/LH / From: JA000001	$1,372.04	2
18125B	LR047324	SHOCK ABSORBER	LR047324 SHOCK ABSORBER Less ACE Suspension, With Continuous Variable Damping / Less Reinforcement, Seal And Nut, RH/LH / To: HA999999	$592.62	2
18125B	LR047324	SHOCK ABSORBER	LR047324 SHOCK ABSORBER Less Electric Engine Battery, With Continuous Variable Damping, With Four Corner Air Suspension / Less Reinforcement, Seal And Nut, RH/LH / From: JA000001	$592.62	2
18125B	LR047324	SHOCK ABSORBER	LR047324 SHOCK ABSORBER Electric Engine Battery-MHEV, With Continuous Variable Damping, With Four Corner Air Suspension / Less Reinforcement, Seal And Nut, RH/LH / From: KA000001	$592.62	2
