Name: Crankshaft/Pistons And Bearings (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001)
Rating: 4.9 (1 reviews)

Crankshaft/Pistons And Bearings (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [4.0 Petrol V6]

View All

Land Rover Discovery 4 (2010-2016) [4.0 Petrol V6] - Crankshaft/Pistons And Bearings (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	1034091	KEY - WOODRUFF	$1.61	To Order

Photo	Part No	Description	Price (each)	Stock
	1021662	NUT - HEX.	$2.44	To Order

Photo	Part No	Description	Price (each)	Stock
	4537629	PISTON AND PIN	$48.38	To Order

Photo	Part No	Description	Price (each)	Stock
	4537608	PIN - PISTON	$3.50	To Order

Photo	Part No	Description	Price (each)	Stock
	LR006264	KIT - PISTON RING	$101.12	To Order
	LR018387	KIT - PISTON RING	$45.63	To Order

Photo	Part No	Description	Price (each)	Stock
	4501414	ROD - CONNECTING	$67.14	To Order

Photo	Part No	Description	Price (each)	Stock
	LR000616	BEARING - CONNECTING ROD	$30.27	To Order
	4345429	BEARING - CONNECTING ROD	$5.61	To Order

Photo	Part No	Description	Price (each)	Stock
	4345511	BOLT - CONNECTING ROD	$5.75	To Order

Photo	Part No	Description	Price (each)	Stock
	4558401	CRANKSHAFT	$835.20	To Order

Photo	Part No	Description	Price (each)	Stock
	3890782	SPACER - BUSH	$4.77	To Order

Photo	Part No	Description	Price (each)	Stock
	4719898	SEAL - CRANKSHAFT OIL	$14.61	To Order

Photo	Part No	Description	Price (each)	Stock
	4676797	GEAR - CRANKSHAFT	$10.68	To Order

Photo	Part No	Description	Price (each)	Stock
	4345513	GEAR - CRANKSHAFT	$25.15	To Order

Photo	Part No	Description	Price (each)	Stock
	LR007194	BEARING - CRANKSHAFT MAIN	$9.21	To Order

Photo	Part No	Description	Price (each)	Stock
	LR004231	BEARING - CRANKSHAFT MAIN	$10.21	To Order

Photo	Part No	Description	Price (each)	Stock
	LR000609	BEARING - CRANKSHAFT MAIN	$8.47	To Order

Photo	Part No	Description	Price (each)	Stock
	LR007198	BEARING - CRANKSHAFT MAIN THRUST	$13.13	To Order

Photo	Part No	Description	Price (each)	Stock
	LR016850	BEARING - CRANKSHAFT MAIN	$138.07	To Order
	LR016851	BEARING - CRANKSHAFT MAIN	$138.07	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HM1	1034091	KEY - WOODRUFF	1034091 KEY - WOODRUFF KEY / From: AA000001	$1.61	1
HN1	1021662	NUT - HEX.	1021662 NUT - HEX. M8 / From: AA000001	$2.44	12
6D309	LR016850	BEARING - CRANKSHAFT MAIN	LR016850 BEARING - CRANKSHAFT MAIN Complete Kit, Refer To Workshop Manual For Proper Grade Selection, STD / From: AA000001	$138.07	1
6D309	LR016851	BEARING - CRANKSHAFT MAIN	LR016851 BEARING - CRANKSHAFT MAIN 0.25 O/S, Complete Kit, Refer To Workshop Manual For Proper Grade Selection / From: AA000001	$138.07	1
6108	4537629	PISTON AND PIN	4537629 PISTON AND PIN From: AA000001	$48.38	6
6135	4537608	PIN - PISTON	4537608 PIN - PISTON From: AA000001	$3.50	6
6148	LR006264	KIT - PISTON RING	LR006264 KIT - PISTON RING Refer To Workshop Manual For Proper Grade Selection, STD / From: AA000001	$101.12	6
6148	LR018387	KIT - PISTON RING	LR018387 KIT - PISTON RING .50mm/.020"O/S / From: AA000001	$45.63	6
6200	4501414	ROD - CONNECTING	4501414 ROD - CONNECTING From: AA000001	$67.14	6
6211	LR000616	BEARING - CONNECTING ROD	LR000616 BEARING - CONNECTING ROD Refer To Workshop Manual For Proper Grade Selection, STD / From: AA000001	$30.27	12
6211	4345429	BEARING - CONNECTING ROD	4345429 BEARING - CONNECTING ROD .010"/.25mm U/S, Refer To Workshop Manual For Proper Grade Selection / From: AA000001	$5.61	12
6214	4345511	BOLT - CONNECTING ROD	4345511 BOLT - CONNECTING ROD From: AA000001	$5.75	12
6303	4558401	CRANKSHAFT	4558401 CRANKSHAFT From: AA000001	$835.20	1
6306A	4676797	GEAR - CRANKSHAFT	4676797 GEAR - CRANKSHAFT Inner / From: AA000001	$10.68	1
6306B	4345513	GEAR - CRANKSHAFT	4345513 GEAR - CRANKSHAFT Outer / From: AA000001	$25.15	1
6333A	LR007194	BEARING - CRANKSHAFT MAIN	LR007194 BEARING - CRANKSHAFT MAIN Lower, STD / From: AA000001	$9.21	3
6333B	LR004231	BEARING - CRANKSHAFT MAIN	LR004231 BEARING - CRANKSHAFT MAIN STD, Upper / From: AA000001	$10.21	3
6337A	LR000609	BEARING - CRANKSHAFT MAIN	LR000609 BEARING - CRANKSHAFT MAIN Lower, STD / From: AA000001	$8.47	1
6337B	LR007198	BEARING - CRANKSHAFT MAIN THRUST	LR007198 BEARING - CRANKSHAFT MAIN THRUST STD, Upper / From: AA000001	$13.13	1
6434	3890782	SPACER - BUSH	3890782 SPACER - BUSH From: AA000001	$4.77	1
6701	4719898	SEAL - CRANKSHAFT OIL	4719898 SEAL - CRANKSHAFT OIL From: AA000001	$14.61	1
