Name: Exhaust Sensors And Modules (3.0 V6 Diesel, Proconve L6 Emissions, Stage V Plus DPF, L6 Diesel Emissions) ((V) FROMAA000001)
Rating: 4.6 (1 reviews)

Exhaust Sensors And Modules (3.0 V6 Diesel, Proconve L6 Emissions, Stage V Plus DPF, L6 Diesel Emissions) ((V) FROMAA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC]

View All

Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC] - Exhaust Sensors And Modules (3.0 V6 Diesel, Proconve L6 Emissions, Stage V Plus DPF, L6 Diesel...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	YYP500100	BOLT	$2.01	To Order

Photo	Part No	Description	Price (each)	Stock
	FS106126	BOLT	$0.50	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR016623	CLIP	$1.65	To Order

Photo	Part No	Description	Price (each)	Stock
	YYC500240	CLAMP - HOSE	$1.99	To Order

Photo	Part No	Description	Price (each)	Stock
	RYP500190	SCREW	$0.62	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR014310	SENSOR - EXHAUST GAS PRESSURE	$199.48	To Order
	LR052422	SENSOR - EXHAUST GAS PRESSURE	$285.18	To Order
	LR052423	SENSOR - EXHAUST GAS PRESSURE	$279.56	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR014227	SENSOR - HEGO	$335.39	To Order

Photo	Part No	Description	Price (each)	Stock
	YQR000050	CLIP - WIRING	$0.76	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	NSC500630	SENSOR - EXHAUST GAS - TEMPERATURE	$167.50	To Order

Photo	Part No	Description	Price (each)	Stock
	LR015455	SENSOR - EXHAUST GAS - TEMPERATURE	$160.46	To Order

Photo	Part No	Description	Price (each)	Stock
	WDN500110	SENSOR - EXHAUST GAS - TEMPERATURE	$162.53	To Order

Photo	Part No	Description	Price (each)	Stock
	LR015454	SENSOR - EXHAUST GAS - TEMPERATURE	$168.48	To Order

Photo	Part No	Description	Price (each)	Stock
	WDN500050	SENSOR - EXHAUST GAS - TEMPERATURE	$121.06	To Order

Photo	Part No	Description	Price (each)	Stock
	LR012788	BRACKET	$93.16	To Order

Photo	Part No	Description	Price (each)	Stock
	YQU500610	BRACKET - 3-WAY CONNECTOR	$30.92	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	YYP500100	BOLT	YYP500100 BOLT M8 X 16MM / From: AA000001	$2.01	2
HB2	FS106126	BOLT IN STOCK	FS106126 BOLT Bracket, Hexagonal Head, M6 x 12MM, Module / From: AA000001 IN STOCK	$0.50	2
HC1	LR016623	CLIP	LR016623 CLIP Stage V Plus DPF / Double / From: AA000001	$1.65	1
HD1	YYC500240	CLAMP - HOSE	YYC500240 CLAMP - HOSE Exhaust Gas Pressure / From: AA000001	$1.99	2
HS1	RYP500190	SCREW IN STOCK	RYP500190 SCREW Hexagonal Head, M6 x 12MM / From: AA000001 IN STOCK	$0.62	1
5H209	LR014310	SENSOR - EXHAUST GAS PRESSURE	LR014310 SENSOR - EXHAUST GAS PRESSURE From: AA000001 / To: DA999999	$199.48	1
5H209	LR052422	SENSOR - EXHAUST GAS PRESSURE	LR052422 SENSOR - EXHAUST GAS PRESSURE With 2 Spd Trans Case With Ctl Trac / From: EA000001 / To: FA999999	$285.18	1
5H209	LR052423	SENSOR - EXHAUST GAS PRESSURE	LR052423 SENSOR - EXHAUST GAS PRESSURE With 1 Speed Transfer Case / From: EA000001 / To: FA999999	$279.56	1
5H209	LR072661	SENSOR - EXHAUST GAS PRESSURE	LR072661 SENSOR - EXHAUST GAS PRESSURE With 2 Spd Trans Case With Ctl Trac / From: GA000001	$199.48	1
5H209	LR072660	SENSOR - EXHAUST GAS PRESSURE	LR072660 SENSOR - EXHAUST GAS PRESSURE With 1 Speed Transfer Case / From: GA000001	$199.48	1
9F472	LR014227	SENSOR - HEGO	LR014227 SENSOR - HEGO LH, Exhaust Gas Oxygen, Front, Lower / From: AA000001	$335.39	1
9J460A	NSC500630	SENSOR - EXHAUST GAS - TEMPERATURE	NSC500630 SENSOR - EXHAUST GAS - TEMPERATURE RH, Exhaust Gas Temperature, Front / From: AA000001	$167.50	1
9J460B	LR015455	SENSOR - EXHAUST GAS - TEMPERATURE	LR015455 SENSOR - EXHAUST GAS - TEMPERATURE LH, Exhaust Gas Temperature, Front, Upper / From: AA000001	$160.46	1
9J460C	WDN500110	SENSOR - EXHAUST GAS - TEMPERATURE	WDN500110 SENSOR - EXHAUST GAS - TEMPERATURE Exhaust Gas Temperature, Middle / From: AA000001	$162.53	1
9J460D	LR015454	SENSOR - EXHAUST GAS - TEMPERATURE	LR015454 SENSOR - EXHAUST GAS - TEMPERATURE Exhaust Gas Temperature, Middle / From: AA000001	$168.48	1
9J460E	WDN500050	SENSOR - EXHAUST GAS - TEMPERATURE	WDN500050 SENSOR - EXHAUST GAS - TEMPERATURE Exhaust Gas Temperature, Rear / From: AA000001	$121.06	1
13A506	YQR000050	CLIP - WIRING IN STOCK	YQR000050 CLIP - WIRING From: AA000001 IN STOCK	$0.76	2
15A024A	LR012788	BRACKET	LR012788 BRACKET From: AA000001	$93.16	1
15A024B	YQU500610	BRACKET - 3-WAY CONNECTOR	YQU500610 BRACKET - 3-WAY CONNECTOR From: AA000001	$30.92	1

Exhaust Sensors And Modules (3.0 V6 Diesel, Proconve L6 Emissions, Stage V Plus Dpf, L6 Diesel...

Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC]

Land Rover Discovery 4 (2010-2016) [3.0 Diesel 24V DOHC TC] - Exhaust Sensors And Modules (3.0 V6 Diesel, Proconve L6 Emissions, Stage V Plus DPF, L6 Diesel...
