Name: Turbocharger (Solihull Plant Build) (3.0 V6 D Low MT ROW, 3.0 V6 D Gen2 Mono Turbo) ((V) FROMFA000001)
Rating: 4.6 (1 reviews)

Turbocharger (Solihull Plant Build) (3.0 V6 D Low MT ROW, 3.0 V6 D Gen2 Mono Turbo) ((V) FROMFA000001) of Land Rover Land Rover Discovery 5 (2017+) [3.0 Diesel 24V DOHC TC]

View All

Land Rover Discovery 5 (2017+) [3.0 Diesel 24V DOHC TC] - Turbocharger (Solihull Plant Build) (3.0 V6 D Low MT ROW, 3.0 V6 D Gen2 Mono Turbo) ((V)...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR014200	BOLT - HEX.HEAD	$1.04	To Order

Photo	Part No	Description	Price (each)	Stock
	1419376	BOLT	$1.54	To Order

Photo	Part No	Description	Price (each)	Stock
	LR023967	BOLT - BANJO	$18.73	To Order

Photo	Part No	Description	Price (each)	Stock
	LR123934	BOLT	$2.46	To Order

Photo	Part No	Description	Price (each)	Stock
	LR106277	NUT - HEX. - FLANGED	$2.08	IN STOCK
	LR106277	NUT - HEX. - FLANGED	$2.08	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR129336	RING - SEALING	$4.94	To Order

Photo	Part No	Description	Price (each)	Stock
	LR006028	SCREW	$2.59	To Order

Photo	Part No	Description	Price (each)	Stock
	RYG500220	SCREW	$3.31	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR000622	SCREW	$0.58	To Order

Photo	Part No	Description	Price (each)	Stock
	RYP500960	SCREW	$0.54	To Order

Photo	Part No	Description	Price (each)	Stock
	4408651	SCREW	$1.22	To Order

Photo	Part No	Description	Price (each)	Stock
	LR008722	CLIP - SPECIAL	$3.92	To Order

Photo	Part No	Description	Price (each)	Stock
	1372726	GASKET - OIL TUBE	$12.80	To Order

Photo	Part No	Description	Price (each)	Stock
	LR061978	HOSE - OIL RETURN	$82.23	To Order

Photo	Part No	Description	Price (each)	Stock
	LR072615	PIPE - OIL FEED	$84.57	To Order

Photo	Part No	Description	Price (each)	Stock
	LR084606	TURBOCHARGER	$2,986.73	To Order

Photo	Part No	Description	Price (each)	Stock
	LR084897	BRACKET - TURBOCHARGER	$38.10	To Order

Photo	Part No	Description	Price (each)	Stock
	LR092499	TUBE - WATER OUTLET	$295.91	To Order

Photo	Part No	Description	Price (each)	Stock
	LR084664	GASKET - EXHAUST MANIFOLD	$59.17	To Order

Photo	Part No	Description	Price (each)	Stock
	LR062102	GASKET - TURBOCHARGER COOLING	$7.62	To Order

Photo	Part No	Description	Price (each)	Stock
	LR013234	GASKET - OIL TUBE	$5.31	To Order

Photo	Part No	Description	Price (each)	Stock
	LR013235	GASKET - OIL RETURN HOSE	$4.94	To Order

Photo	Part No	Description	Price (each)	Stock
	LR061993	HEAT SHIELD - TURBOCHARGER	$26.41	To Order

Photo	Part No	Description	Price (each)	Stock
	LR061991	HEAT SHIELD - TURBOCHARGER	$39.52	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR014200	BOLT - HEX.HEAD	LR014200 BOLT - HEX.HEAD Hexagonal Head, M6 X 10MM	$1.04	5
HB2	1419376	BOLT	1419376 BOLT Hexagonal Head, M8 X 16MM	$1.54	4
HB3	LR023967	BOLT - BANJO	LR023967 BOLT - BANJO Banjo Bolt, Hexagonal Head, Service Part May Differ From Production, Turbocharger Oil Feed	$18.73	1
HB4	LR123934	BOLT	LR123934 BOLT M6 x 12MM, Torx	$2.46	1
HN1	LR106277	NUT - HEX. - FLANGED IN STOCK	LR106277 NUT - HEX. - FLANGED M8 / To: JA059933 IN STOCK	$2.08	3
HN1	LR106277	NUT - HEX. - FLANGED IN STOCK	LR106277 NUT - HEX. - FLANGED M8 / From: JA059934 IN STOCK	$2.08	3
HR1	LR129336	RING - SEALING	LR129336 RING - SEALING 11.2 X 1.8	$4.94	1
HS1	LR006028	SCREW	LR006028 SCREW M6 X 16MM, Torx	$2.59	2
HS2	RYG500220	SCREW IN STOCK	RYG500220 SCREW Hexagonal Head, M6 X 20MM IN STOCK	$3.31	2
HS3	LR000622	SCREW	LR000622 SCREW M6 x 12MM, Tube	$0.58	1
HS4	RYP500960	SCREW	RYP500960 SCREW M6 X 16MM, Torx	$0.54	2
HS5	4408651	SCREW	4408651 SCREW M6 X 14MM	$1.22	1
6K677	LR061978	HOSE - OIL RETURN	LR061978 HOSE - OIL RETURN	$82.23	1
6K679	LR072615	PIPE - OIL FEED	LR072615 PIPE - OIL FEED Includes Banjo Bolt	$84.57	1
6K682	LR084606	TURBOCHARGER	LR084606 TURBOCHARGER Primary	$2,986.73	1
6N652A	LR013234	GASKET - OIL TUBE	LR013234 GASKET - OIL TUBE Lower	$5.31	1
6N652B	LR013235	GASKET - OIL RETURN HOSE	LR013235 GASKET - OIL RETURN HOSE Gasket - Turbocharger Oil Return Hose, Upper	$4.94	1
7N649	LR084897	BRACKET - TURBOCHARGER	LR084897 BRACKET - TURBOCHARGER Turbocharger Inlet	$38.10	1
8A505	LR092499	TUBE - WATER OUTLET	LR092499 TUBE - WATER OUTLET Cooling For Turbocharger	$295.91	1
9A397A	LR061993	HEAT SHIELD - TURBOCHARGER	LR061993 HEAT SHIELD - TURBOCHARGER RH, Manifold To Turbocharger	$26.41	1
9A397B	LR061991	HEAT SHIELD - TURBOCHARGER	LR061991 HEAT SHIELD - TURBOCHARGER Turbocharger	$39.52	1
6238	LR008722	CLIP - SPECIAL	LR008722 CLIP - SPECIAL	$3.92	2
9448A	LR084664	GASKET - EXHAUST MANIFOLD	LR084664 GASKET - EXHAUST MANIFOLD Manifold To Turbocharger	$59.17	1
9448B	LR062102	GASKET - TURBOCHARGER COOLING	LR062102 GASKET - TURBOCHARGER COOLING Cooling For Turbocharger	$7.62	1
9450	1372726	GASKET - OIL TUBE	1372726 GASKET - OIL TUBE Banjo Washer	$12.80	1
