Air Conditioning Condensr/Compressr (Front) (3.0L AJ20P6 Petrol High, 3.0L AJ20D6 Diesel High) ((V) FROMKA000001) of Land Rover Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol]

View All

Land Rover Range Rover (2012-2021) [5.0 OHC SGDI SC V8 Petrol] - Air Conditioning Condensr/Compressr (Front) (3.0L AJ20P6 Petrol High, 3.0L AJ20D6 Diesel High) ((V)...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR005074	BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	FB108076	BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR035462	CLIP - HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	FN106046	NUT - HEX.	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR044466	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR054871	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR054870	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	FS106166	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR018707	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	RYG500160	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR133116	CONDENSER	Enquire	To Order
	LR181384	CONDENSER	Enquire	To Order
	LR137975	CONDENSER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR062331	BRACKET - RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR063161	BRACKET - INTERCOOLER RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR063162	BRACKET - INTERCOOLER RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR063164	BRACKET - INTERCOOLER RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR063165	BRACKET - INTERCOOLER RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR086926	SENSOR - REFRIGERANT PRESSURE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR082205	HOSE - AIR CONDITIONING	Enquire	To Order
	LR135856	HOSE - AIR CONDITIONING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR112585	COMPRESSOR - AIR CONDITIONING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR123056	BRACKET - COMPRESSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR120445	TUBE - A/C COMPRESSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR120446	TUBE - COMPRESSOR LINE	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
HB1	LR005074	BOLT	LR005074 BOLT Hexagonal Head, M8 X 96.5 / From: KA000001	-	3	Enquire
HB2	FB108076	BOLT	FB108076 BOLT M8 X 35MM / From: KA000001	-	4	Enquire
HC1	LR035462	CLIP - HOSE	LR035462 CLIP - HOSE For Air Conditioning Hose / From: KA000001	-	1	Enquire
HN1	FN106046	NUT - HEX.	FN106046 NUT - HEX. Hexagonal Head, M6 / From: KA000001	-	6	Enquire
HR1	LR044466	O-RING	LR044466 O-RING 7.65 X 1.78 / From: KA000001	-	4	Enquire
HR2	LR054871	O-RING	LR054871 O-RING 10.82MM X 1.78MM / From: KA000001	-	4	Enquire
HR3	LR054870	O-RING	LR054870 O-RING 16.5 X 1.78MM / From: KA000001	-	4	Enquire
HS1	FS106166	SCREW	FS106166 SCREW Hexagonal Head, M6 X 16MM / From: KA000001	-	2	Enquire
HS2	LR018707	SCREW	LR018707 SCREW 6X20, Hexagonal Head / From: KA000001	-	2	Enquire
HS3	RYG500160	SCREW	RYG500160 SCREW Hexagonal Head, M6 X 14MM / From: KA000001	-	1	Enquire
8A291	LR062331	BRACKET - RADIATOR	LR062331 BRACKET - RADIATOR Air Conditioning Condenser / From: KA000001	-	2	Enquire
12A644	LR086926	SENSOR - REFRIGERANT PRESSURE	LR086926 SENSOR - REFRIGERANT PRESSURE Refrigerant Pressure Sensor / From: KA000001	-	1	Enquire
18B402	LR082205	HOSE - AIR CONDITIONING	LR082205 HOSE - AIR CONDITIONING Condenser Outlet / From: KA000001 / To: LA590569	-	1	Enquire
18B402	LR135856	HOSE - AIR CONDITIONING	LR135856 HOSE - AIR CONDITIONING Condenser Outlet / From: LA590570	-	1	Enquire
19D623	LR112585	COMPRESSOR - AIR CONDITIONING	LR112585 COMPRESSOR - AIR CONDITIONING From: KA000001	-	1	Enquire
19D624	LR123056	BRACKET - COMPRESSOR	LR123056 BRACKET - COMPRESSOR Air Conditioning Compressor Bracket / From: KA000001	-	1	Enquire
19N651A	LR120445	TUBE - A/C COMPRESSOR	LR120445 TUBE - A/C COMPRESSOR Compressor Inlet / From: KA000001	-	1	Enquire
19N651B	LR120446	TUBE - COMPRESSOR LINE	LR120446 TUBE - COMPRESSOR LINE Condenser Inlet Tube / From: KA000001	-	1	Enquire
12257A	LR063161	BRACKET - INTERCOOLER RADIATOR	LR063161 BRACKET - INTERCOOLER RADIATOR 3.0L AJ20D6 Diesel High / RH Upper / From: LA000001	-	1	Enquire
12257B	LR063162	BRACKET - INTERCOOLER RADIATOR	LR063162 BRACKET - INTERCOOLER RADIATOR 3.0L AJ20D6 Diesel High / LH Upper / From: LA000001	-	1	Enquire
12257C	LR063164	BRACKET - INTERCOOLER RADIATOR	LR063164 BRACKET - INTERCOOLER RADIATOR 3.0L AJ20D6 Diesel High / LH Lower / From: LA000001	-	1	Enquire
12257D	LR063165	BRACKET - INTERCOOLER RADIATOR	LR063165 BRACKET - INTERCOOLER RADIATOR 3.0L AJ20D6 Diesel High / RH Lower / From: LA000001	-	1	Enquire
19712	LR133116	CONDENSER	LR133116 CONDENSER 3.0L AJ20P6 Petrol High / From: KA000001 / To: LA589181	-	1	Enquire
19712	LR181384	CONDENSER	LR181384 CONDENSER 3.0L AJ20D6 Diesel High / From: LA000001	-	1	Enquire
19712	LR137975	CONDENSER	LR137975 CONDENSER 3.0L AJ20P6 Petrol High / From: LA589182	-	1	Enquire
