Name: Exhaust Sensors And Modules (5.0L P AJ133 DOHC CDA S/C Enhanced) ((V) FROMKA000001)
Rating: 4.4 (1 reviews)

Exhaust Sensors And Modules (5.0L P AJ133 DOHC CDA S/C Enhanced) ((V) FROMKA000001) of Land Rover Land Rover Range Rover Velar (2017+) [5.0 OHC SGDI SC V8 Petrol]

View All

Land Rover Range Rover Velar (2017+) [5.0 OHC SGDI SC V8 Petrol] - Exhaust Sensors And Modules (5.0L P AJ133 DOHC CDA S/C Enhanced) ((V) FROMKA000001)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR000385	BOLT	$0.63	To Order

Photo	Part No	Description	Price (each)	Stock
	LR011519	CLIP	$1.97	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	FN105042	NUT - HEX. - FLANGED	$0.50	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	RYP500200	SCREW	$0.90	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091869	SHIELD - PROTECTION	$18.80	To Order

Photo	Part No	Description	Price (each)	Stock
	LR126303	SENSOR	$184.11	To Order

Photo	Part No	Description	Price (each)	Stock
	LR126305	SENSOR	$200.17	To Order

Photo	Part No	Description	Price (each)	Stock
	LR117023	SENSOR - LAMBDA	$251.98	To Order
	LR134944	SENSOR - LAMBDA	$265.33	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091883	SENSOR - EXHAUST GAS - OXYGEN	$158.84	To Order
	LR140061	SENSOR - EXHAUST GAS - OXYGEN	$284.95	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091882	SENSOR - EXHAUST GAS - OXYGEN	$188.85	To Order
	LR140063	SENSOR - EXHAUST GAS - OXYGEN	$192.55	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091884	SENSOR - EXHAUST GAS - OXYGEN	$148.70	To Order
	LR140038	SENSOR - EXHAUST GAS - OXYGEN	$190.78	To Order

Photo	Part No	Description	Price (each)	Stock
	LR092949	BRACKET - WIRING	$14.84	To Order

Photo	Part No	Description	Price (each)	Stock
	LR104498	BRACKET	$34.89	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR000385	BOLT	LR000385 BOLT Bracket, Hexagonal Head, M6 x 12MM / From: KA000001	$0.63	3
HC1	LR011519	CLIP IN STOCK	LR011519 CLIP 9.5 X 6 X 2 / From: KA000001 IN STOCK	$1.97	3
HN1	FN105042	NUT - HEX. - FLANGED IN STOCK	FN105042 NUT - HEX. - FLANGED M5 / From: KA000001 IN STOCK	$0.50	4
HS1	RYP500200	SCREW	RYP500200 SCREW Hexagonal Head, M6 X 20MM / From: KA000001	$0.90	2
5H209A	LR126303	SENSOR	LR126303 SENSOR LH, Gasoline Particulate Filter Pressure Sensor / From: KA000001	$184.11	1
5H209B	LR126305	SENSOR	LR126305 SENSOR RH, Gasoline Particulate Filter Pressure Sensor / From: KA000001	$200.17	1
5K286	LR091869	SHIELD - PROTECTION	LR091869 SHIELD - PROTECTION From: KA000001	$18.80	1
9F472A	LR117023	SENSOR - LAMBDA	LR117023 SENSOR - LAMBDA Exhaust Gas Oxygen, Front, RH And LH / From: KA000001 / To: KA228498	$251.98	2
9F472A	LR134944	SENSOR - LAMBDA	LR134944 SENSOR - LAMBDA Exhaust Gas Oxygen, Front, RH And LH / From: KA228499	$265.33	2
9F472B	LR091883	SENSOR - EXHAUST GAS - OXYGEN	LR091883 SENSOR - EXHAUST GAS - OXYGEN LH, Front / Rear, Hego Sensor / From: KA000001 / To: LA275774	$158.84	1
9F472B	LR140061	SENSOR - EXHAUST GAS - OXYGEN	LR140061 SENSOR - EXHAUST GAS - OXYGEN LH, Front / Rear, Hego Sensor / From: LA275775	$284.95	2
9F472C	LR091882	SENSOR - EXHAUST GAS - OXYGEN	LR091882 SENSOR - EXHAUST GAS - OXYGEN RH, Front, Hego Sensor / From: KA000001 / To: LA275774	$188.85	1
9F472C	LR140063	SENSOR - EXHAUST GAS - OXYGEN	LR140063 SENSOR - EXHAUST GAS - OXYGEN RH, Front, Hego Sensor / From: LA275775	$192.55	1
9F472D	LR091884	SENSOR - EXHAUST GAS - OXYGEN	LR091884 SENSOR - EXHAUST GAS - OXYGEN Front, Hego Sensor, Rear / From: KA000001 / To: LA274283	$148.70	1
9F472D	LR140038	SENSOR - EXHAUST GAS - OXYGEN	LR140038 SENSOR - EXHAUST GAS - OXYGEN Front, Hego Sensor, Rear / From: LA274284	$190.78	1
14A254A	LR092949	BRACKET - WIRING	LR092949 BRACKET - WIRING Hego Sensor, LH Front / From: KA000001	$14.84	1
14A254B	LR104498	BRACKET	LR104498 BRACKET Rear / From: KA000001	$34.89	1

Exhaust Sensors And Modules (5.0L P Aj133 Dohc Cda S/C Enhanced) ((V) Fromka000001)

Land Rover Range Rover Velar (2017+) [5.0 OHC SGDI SC V8 Petrol]

Land Rover Range Rover Velar (2017+) [5.0 OHC SGDI SC V8 Petrol] - Exhaust Sensors And Modules (5.0L P AJ133 DOHC CDA S/C Enhanced) ((V) FROMKA000001)
