Heater Hoses (3.0L DOHC GDI SC V6 PETROL, Less Heater, With Ptc Heater, 5.0L P AJ133 DOHC CDA S/C Enhanced) of Land Rover Land Rover Range Rover Velar (2017+) [3.0 I6 Turbo Diesel AJ20D6]

View All

Land Rover Range Rover Velar (2017+) [3.0 I6 Turbo Diesel AJ20D6] - Heater Hoses (3.0L DOHC GDI SC V6 PETROL, Less Heater, With Ptc Heater, 5.0L P AJ133 DOHC CDA S/C...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	FS106166	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR011270	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR010793	GASKET - WATER MANIFOLD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091877	HOSE - WATER	Enquire	To Order
	LR110260	HOSE - WATER	Enquire	To Order
	LR135629	HOSE - WATER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091463	HOSE - HEATER WATER	Enquire	To Order
	LR116939	HOSE - HEATER WATER	Enquire	To Order
	LR135630	HOSE - HEATER WATER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091457	HOSE - HEATER WATER	Enquire	To Order
	LR114319	HOSE - HEATER WATER	Enquire	To Order
	LR117017	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR041442	SENSOR - ENGINE COOLANT TEMPERATURE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR087558	MANIFOLD - HEATER	Enquire	To Order
	LR109401	MANIFOLD - HEATER	Enquire	To Order
	LR122710	MANIFOLD - HEATER	Enquire	To Order

...and 1 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
HS1	FS106166	SCREW	FS106166 SCREW Hexagonal Head, M6 X 16MM	-	2	Enquire
HS2	LR011270	SCREW	LR011270 SCREW M6 x 25MM, Torx	-	6	Enquire
12A648	LR041442	SENSOR - ENGINE COOLANT TEMPERATURE	LR041442 SENSOR - ENGINE COOLANT TEMPERATURE	-	1	Enquire
18N349	LR087558	MANIFOLD - HEATER	LR087558 MANIFOLD - HEATER To: JA726229	-	1	Enquire
18N349	LR109401	MANIFOLD - HEATER	LR109401 MANIFOLD - HEATER From: JA726230 / To: KA792019	-	1	Enquire
18N349	LR122710	MANIFOLD - HEATER	LR122710 MANIFOLD - HEATER 3.0L DOHC GDI SC V6 PETROL / From: KA792020	-	1	Enquire
18N349	LR122711	MANIFOLD - HEATER	LR122711 MANIFOLD - HEATER 5.0L P AJ133 DOHC CDA S/C Enhanced / From: KA792020	-	1	Enquire
8255	LR010793	GASKET - WATER MANIFOLD	LR010793 GASKET - WATER MANIFOLD	-	2	Enquire
8260	LR091877	HOSE - WATER	LR091877 HOSE - WATER 3.0L DOHC GDI SC V6 PETROL / To: KA778648	-	1	Enquire
8260	LR110260	HOSE - WATER	LR110260 HOSE - WATER 3.0L DOHC GDI SC V6 PETROL / From: KA778649	-	1	Enquire
8260	LR135629	HOSE - WATER	LR135629 HOSE - WATER 5.0L P AJ133 DOHC CDA S/C Enhanced / From: KA000001	-	1	Enquire
18472	LR091463	HOSE - HEATER WATER	LR091463 HOSE - HEATER WATER 3.0L DOHC GDI SC V6 PETROL	-	1	Enquire
18472	LR116939	HOSE - HEATER WATER	LR116939 HOSE - HEATER WATER 5.0L P AJ133 DOHC CDA S/C Enhanced / From: KA000001 / To: LA251888	-	1	Enquire
18472	LR135630	HOSE - HEATER WATER	LR135630 HOSE - HEATER WATER 5.0L P AJ133 DOHC CDA S/C Enhanced / From: LA251889	-	1	Enquire
18663	LR091457	HOSE - HEATER WATER	LR091457 HOSE - HEATER WATER To: JA778426	-	1	Enquire
18663	LR114319	HOSE - HEATER WATER	LR114319 HOSE - HEATER WATER 3.0L DOHC GDI SC V6 PETROL / From: JA778427	-	1	Enquire
18663	LR117017	HOSE	LR117017 HOSE 5.0L P AJ133 DOHC CDA S/C Enhanced / From: KA000001	-	1	Enquire
