Turbocharger (Lubrication And Cooling) (3.0L Aj20D6 Diesel High) ((V) Fromla000001)

Land Rover Range Rover Velar (2017+) [3.0 I6 Turbo Diesel AJ20D6]

Find Your Part

Land Rover Range Rover Velar (2017+) [3.0 I6 Turbo Diesel AJ20D6] - Turbocharger (Lubrication And Cooling) (3.0L AJ20D6 Diesel High) ((V) FROMLA000001)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR125467 RING - SEALING $11.56 To Order
Photo Part No Description Price (each) Stock
LR125463 RING - SEALING $12.40 To Order
Photo Part No Description Price (each) Stock
LR165689 RING - SEALING $6.09 To Order
Photo Part No Description Price (each) Stock
LR165690 RING - SEALING $6.09 To Order
Photo Part No Description Price (each) Stock
LR073655 SCREW $1.54 IN STOCK
Photo Part No Description Price (each) Stock
LR122683 SCREW $1.81 IN STOCK
Photo Part No Description Price (each) Stock
LR073671 WASHER - COPPER $4.48 IN STOCK
Photo Part No Description Price (each) Stock
LR125470 PIPE - OIL DRAIN $47.37 To Order
LR161061 PIPE - OIL DRAIN $66.07 To Order
Photo Part No Description Price (each) Stock
LR125469 HOSE - OIL RETURN $34.82 To Order
Photo Part No Description Price (each) Stock
LR125347 HOSE - OIL RETURN $42.03 To Order
Photo Part No Description Price (each) Stock
LR125479 HOSE - WATER $89.31 To Order
Photo Part No Description Price (each) Stock
LR125495 HOSE - INTERCOOLER $214.51 To Order
Photo Part No Description Price (each) Stock
LR125478 HOSE - INTERCOOLER $39.66 To Order
Photo Part No Description Price (each) Stock
LR125619 TUBE - WATER OUTLET $203.32 To Order
Photo Part No Description Price (each) Stock
LR125620 TUBE - WATER OUTLET $81.18 To Order
View All
Turbocharger (Lubrication And Cooling) (3.0L AJ20D6 Diesel High) ((V) FROMLA000001) of Land Rover Land Rover Range Rover Velar (2017+) [3.0 I6 Turbo Diesel AJ20D6] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HR1 LR125467
RING - SEALING
9.25MM x 1.78MM / From: MA000001 		$11.56 2
HR2 LR125463
RING - SEALING 		$12.40 3
HR3 LR165689
RING - SEALING
Low Pressure Turbocharger, 		$6.09 1
HR4 LR165690
RING - SEALING
Both Turbochargers, 		$6.09 1
HS1 LR073655
SCREW
Hexagonal Head, M6 X 20MM / From: MA000001
IN STOCK 		$1.54 4
HS2 LR122683
SCREW
M6 X 16MM / From: MA000001
IN STOCK 		$1.81 4
6K677A LR125469
HOSE - OIL RETURN
High Pressure Turbocharger / From: MA000001 		$34.82 1
6K677B LR125347
HOSE - OIL RETURN
Low Pressure Turbocharger / From: MA000001 		$42.03 1
6K679 LR125470
PIPE - OIL DRAIN
Both Turbochargers / From: MA000001 / To: MA317658 		$47.37 1
6K679 LR161061
PIPE - OIL DRAIN
Both Turbochargers / From: MA317659 		$66.07 1
6K683A LR125479
HOSE - WATER
Both Turbochargers, Water Inlet / From: MA000001 		$89.31 1
6K683B LR125495
HOSE - INTERCOOLER
High Pressure Turbocharger, Water Inlet / From: MA000001 		$214.51 1
6K683C LR125478
HOSE - INTERCOOLER
Low Pressure Turbocharger, Water Outlet / From: MA000001 		$39.66 1
8A520A LR125619
TUBE - WATER OUTLET
High Pressure Turbocharger, Water Outlet / From: MA000001 		$203.32 1
8A520B LR125620
TUBE - WATER OUTLET
Both Turbochargers, Water Outlet / From: MA000001 		$81.18 1
9450 LR073671
WASHER - COPPER
Banjo Washer, Requires 2 Pcs Per Banjo-Bolt, Turbocharger Oil Feed / From: MA000001
IN STOCK 		$4.48 4
