Name: Fuel Injection Pump-Engine Mounted (Solihull Plant Build) (2.0L AJ200P Hi PHEV, 2.0L I4 High DOHC AJ200 Petrol, 2.0L I4 Mid DOHC AJ200 Petrol) ((V) FROMHA000001)
Rating: 4.4 (1 reviews)

Fuel Injection Pump-Engine Mounted (Solihull Plant Build) (2.0L AJ200P Hi PHEV, 2.0L I4 High DOHC AJ200 Petrol, 2.0L I4 Mid DOHC AJ200 Petrol) ((V) FROMHA000001) of Land Rover Land Rover Range Rover Velar (2017+) [2.0 Turbo Petrol AJ200P]

View All

Land Rover Range Rover Velar (2017+) [2.0 Turbo Petrol AJ200P] - Fuel Injection Pump-Engine Mounted (Solihull Plant Build) (2.0L AJ200P Hi PHEV, 2.0L I4 High DOHC...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR074133	BOLT	$2.17	To Order

Photo	Part No	Description	Price (each)	Stock
	LR092106	SCREW	$0.95	To Order

Photo	Part No	Description	Price (each)	Stock
	LR073655	SCREW	$1.54	IN STOCK
	LR108591	BOLT	$1.01	To Order

Photo	Part No	Description	Price (each)	Stock
	LR073724	SCREW	$1.96	To Order

Photo	Part No	Description	Price (each)	Stock
	LR089197	STUD	$3.82	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091758	TAPPET	$23.83	To Order

Photo	Part No	Description	Price (each)	Stock
	LR010861	O-RING	$11.16	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR091586	PUMP - FUEL	$567.34	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091589	PIPE - FUEL	$65.20	To Order

Photo	Part No	Description	Price (each)	Stock
	LR129378	BRACKET - FUEL PUMP	$60.74	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091588	PIPE - FUEL	$35.44	To Order

Photo	Part No	Description	Price (each)	Stock
	LR091590	BRACKET - FUEL TUBE SUPPORT	$35.06	To Order
	LR107666	BRACKET - FUEL TUBE SUPPORT	$34.36	To Order
	LR126243	BRACKET	$34.36	To Order

...and 1 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR074133	BOLT	LR074133 BOLT M10 X 30MM, Shield	$2.17	1
HS1	LR092106	SCREW	LR092106 SCREW Fuel Pump, M6 x 25MM	$0.95	2
HS2	LR073655	SCREW IN STOCK	LR073655 SCREW Bracket, Hexagonal Head, M6 X 20MM / To: JA700056 IN STOCK	$1.54	2
HS2	LR108591	BOLT	LR108591 BOLT Bracket, M6 X 16MM / From: JA700057	$1.01	2
HS3	LR073724	SCREW	LR073724 SCREW M8 X 25MM, Shield	$1.96	3
HT1	LR089197	STUD	LR089197 STUD M6 x 22 mm + M6 x 12 mm	$3.82	1
9A337	LR091589	PIPE - FUEL	LR091589 PIPE - FUEL Fuel Pump	$65.20	1
9B552	LR129378	BRACKET - FUEL PUMP	LR129378 BRACKET - FUEL PUMP Fuel Pump	$60.74	1
9K299	LR091588	PIPE - FUEL	LR091588 PIPE - FUEL To Fuel Rail	$35.44	1
9N653	LR091590	BRACKET - FUEL TUBE SUPPORT	LR091590 BRACKET - FUEL TUBE SUPPORT To: JA747153	$35.06	1
9N653	LR107666	BRACKET - FUEL TUBE SUPPORT	LR107666 BRACKET - FUEL TUBE SUPPORT From: JA747154 / To: KA207700	$34.36	1
9N653	LR126243	BRACKET	LR126243 BRACKET From: KA207701 / To: KA999999	$34.36	1
9N653	LR126845	BRACKET - FUEL TUBE SUPPORT	LR126845 BRACKET - FUEL TUBE SUPPORT From: LA000001	$31.67	1
6500	LR091758	TAPPET	LR091758 TAPPET For Fuel Pump	$23.83	1
6643	LR010861	O-RING IN STOCK	LR010861 O-RING 31MM X 2MM, Fuel Pump IN STOCK	$11.16	1
9350	LR091586	PUMP - FUEL	LR091586 PUMP - FUEL	$567.34	1
