Name: Intercooler/Air Ducts And Hoses (Solihull Plant Build) (2.0L I4 DSL HIGH DOHC AJ200, 2.0L I4 DSL MID DOHC AJ200) ((V) FROMHA000001)
Rating: 5.0 (1 reviews)

Intercooler/Air Ducts And Hoses (Solihull Plant Build) (2.0L I4 DSL HIGH DOHC AJ200, 2.0L I4 DSL MID DOHC AJ200) ((V) FROMHA000001) of Land Rover Land Rover Range Rover Sport (2014+) [2.0 Turbo Diesel]

View All

Land Rover Range Rover Sport (2014+) [2.0 Turbo Diesel] - Intercooler/Air Ducts And Hoses (Solihull Plant Build) (2.0L I4 DSL HIGH DOHC AJ200, 2.0L I4 DSL...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR001080	BOLT	$1.31	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR092322	BOLT	$4.24	To Order

Photo	Part No	Description	Price (each)	Stock
	LR082407	BOLT - HEX.HEAD	$4.34	To Order

Photo	Part No	Description	Price (each)	Stock
	FX106046	NUT - FLANGED	$0.61	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR082392	INSULATOR - INTERCOOLER	$6.52	To Order

Photo	Part No	Description	Price (each)	Stock
	LR082394	BRACKET - CHARGE AIR COOLER	$37.59	To Order
	LR082394	BRACKET - CHARGE AIR COOLER	$37.59	To Order

Photo	Part No	Description	Price (each)	Stock
	LR082398	BUSH - INSULATING	$12.14	To Order

Photo	Part No	Description	Price (each)	Stock
	LR139045	INTERCOOLER	$219.40	To Order

Photo	Part No	Description	Price (each)	Stock
	LR071745	SENSOR - AIR CHARGE TEMPERATURE	$46.63	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	LR001080	BOLT IN STOCK	LR001080 BOLT Hexagonal Head, M6 X 40MM / From: HA000001 IN STOCK	$1.31	4
HB2	LR092322	BOLT	LR092322 BOLT Hexagonal Head, M12 X 70MM / From: HA000001	$4.24	1
HB3	LR082407	BOLT - HEX.HEAD	LR082407 BOLT - HEX.HEAD M12 x 80MM / From: HA000001	$4.34	1
HN1	FX106046	NUT - FLANGED IN STOCK	FX106046 NUT - FLANGED Hexagonal Head, M6 / From: HA000001 IN STOCK	$0.61	1
6K864	LR082394	BRACKET - CHARGE AIR COOLER	LR082394 BRACKET - CHARGE AIR COOLER From: HA000001 / To: JA155665	$37.59	1
6K864	LR082394	BRACKET - CHARGE AIR COOLER	LR082394 BRACKET - CHARGE AIR COOLER From: JA155666	$37.59	1
9L440	LR139045	INTERCOOLER	LR139045 INTERCOOLER From: HA000001	$219.40	1
12A697	LR071745	SENSOR - AIR CHARGE TEMPERATURE	LR071745 SENSOR - AIR CHARGE TEMPERATURE From: HA000001	$46.63	1
8124	LR082392	INSULATOR - INTERCOOLER	LR082392 INSULATOR - INTERCOOLER From: HA000001	$6.52	8
88105	LR082398	BUSH - INSULATING	LR082398 BUSH - INSULATING From: HA000001	$12.14	1
