Intercooler/Air Ducts And Hoses (2.2L Cr Di 16V Diesel)

Land Rover Range Rover Evoque (2012-2018) [2.2 Single Turbo Diesel]

Find Your Part

Land Rover Range Rover Evoque (2012-2018) [2.2 Single Turbo Diesel] - Intercooler/Air Ducts And Hoses (2.2L CR DI 16V Diesel)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
LR024636 CLAMP - HOSE Enquire To Order
Photo Part No Description Price (each) Stock
FX108046 NUT - LOCKING Enquire To Order
Photo Part No Description Price (each) Stock
FS106166 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
RYP500810 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
LR024302 DUCT - AIR Enquire To Order
LR038315 DUCT - AIR Enquire To Order
LR041818 DUCT - AIR Enquire To Order
...and 3 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR024515 HOSE - INTERCOOLER Enquire To Order
LR041817 HOSE - INTERCOOLER Enquire To Order
LR050228 HOSE - INTERCOOLER Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
LR031466 INTERCOOLER Enquire To Order
Photo Part No Description Price (each) Stock
LR021587 SENSOR - AIR TEMPERATURE & PRESSURE Enquire To Order
Photo Part No Description Price (each) Stock
LR066436 HOSE - INTERCOOLER Enquire To Order
LR024304 HOSE - INTERCOOLER Enquire To Order
Photo Part No Description Price (each) Stock
LR024632 HOSE - TURBOCHARGER INLET Enquire To Order
View All
Intercooler/Air Ducts And Hoses (2.2L CR DI 16V Diesel) of Land Rover Land Rover Range Rover Evoque (2012-2018) [2.2 Single Turbo Diesel] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HD1 LR024636
CLAMP - HOSE
50-70MM 		- 2 Enquire
HN1 FX108046
NUT - LOCKING
M8 		- 1 Enquire
HS1 FS106166
SCREW
Hexagonal Head, M6 X 16MM 		- 3 Enquire
HS2 RYP500810
SCREW
Hexagonal Head, M5 x 20MM, MAP Sensor 		- 1 Enquire
6C646 LR024302
DUCT - AIR
Turbocharger To Intercooler / To: CH675361 		- 1 Enquire
6C646 LR038315
DUCT - AIR
Turbocharger To Intercooler / From: CH675362 / To: CH999999 		- 1 Enquire
6C646 LR041818
DUCT - AIR
Turbocharger To Intercooler / From: DH000001 / To: DH999999 		- 1 Enquire
6C646 LR049693
DUCT - AIR
Turbocharger To Intercooler / From: EH000001 / To: FH971981 		- 1 Enquire
6C646 LR063942
DUCT - AIR
Turbocharger To Intercooler / From: FH971982 / To: FH999999 		- 1 Enquire
6C646 LR110361
DUCT - AIR
Turbocharger To Intercooler / From: GH000001 / To: GH999999 		- 1 Enquire
6K683A LR066436
HOSE - INTERCOOLER
Intercooler To Throttle Body / From: FH970045 		- 1 Enquire
6K683A LR024304
HOSE - INTERCOOLER
Intercooler To Throttle Body / To: FH970044 		- 1 Enquire
6K683B LR024632
HOSE - TURBOCHARGER INLET
Connection, Turbocharger Outlet 		- 1 Enquire
9B613 LR024515
HOSE - INTERCOOLER
Connection, Intercooler Inlet / To: CH675361 		- 1 Enquire
9B613 LR041817
HOSE - INTERCOOLER
Connection, Intercooler Inlet / From: CH675362 / To: DH999999 		- 1 Enquire
9B613 LR050228
HOSE - INTERCOOLER
Connection, Intercooler Inlet / From: EH000001 / To: FH971981 		- 1 Enquire
9B613 LR063944
HOSE - INTERCOOLER
Connection, Intercooler Inlet / From: FH971982 		- 1 Enquire
9L440 LR031466
INTERCOOLER 		- 1 Enquire
12A697 LR021587
SENSOR - AIR TEMPERATURE & PRESSURE
Sensor - Air Temperature And Pressure 		- 1 Enquire
