Land Rover Range Rover Evoque (2012-2018) [2.0 Turbo Diesel] - Transmission Cooling Systems (2.0L 16V TIVCT T/C 240PS Petrol, 6 Speed Auto AWF21 AWD, For Hot...

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
RYG501000 BOLT AND WASHER - HEX.HEAD Enquire To Order
Photo Part No Description Price (each) Stock
LR003125 RING - SEALING Enquire To Order
Photo Part No Description Price (each) Stock
LR001101 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
RYG500630 SCREW AND WASHER Enquire To Order
Photo Part No Description Price (each) Stock
LR024623 HOSE - OIL COOLER Enquire To Order
LR032863 HOSE - OIL COOLER Enquire To Order
Photo Part No Description Price (each) Stock
LR024552 HOSE - OIL COOLER Enquire To Order
LR032861 HOSE - OIL COOLER Enquire To Order
Photo Part No Description Price (each) Stock
LR003132 HOSE - OIL COOLER Enquire To Order
Photo Part No Description Price (each) Stock
LR002916 OIL COOLER Enquire To Order
Photo Part No Description Price (each) Stock
LR006105 OIL COOLER Enquire To Order
View All
Transmission Cooling Systems (2.0L 16V TIVCT T/C 240PS Petrol, 6 Speed Auto AWF21 AWD, For Hot Climate Zones) of Land Rover Land Rover Range Rover Evoque (2012-2018) [2.0 Turbo Diesel] Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
HB1 RYG501000
BOLT AND WASHER - HEX.HEAD
Hexagonal Head, M8 X 21MM 		- 1 Enquire
HR1 LR003125
RING - SEALING
11.3 x 2.5MM, O-Ring 		- 2 Enquire
HS1 LR001101
SCREW
6X20, Hexagonal Head 		- 1 Enquire
HS2 RYG500630
SCREW AND WASHER
Bolt And Washer, M6X16, Torx 		- 2 Enquire
7A095A LR002916
OIL COOLER
Side, Small 		- 1 Enquire
7A095B LR006105
OIL COOLER
Front, Large 		- 1 Enquire
7890A LR024623
HOSE - OIL COOLER
Gearbox, Inlet / To: CH646560 		- 1 Enquire
7890A LR032863
HOSE - OIL COOLER
Gearbox, Inlet / From: CH646561 		- 1 Enquire
7890B LR024552
HOSE - OIL COOLER
Gearbox, Output / To: CH647865 		- 1 Enquire
7890B LR032861
HOSE - OIL COOLER
Gearbox, Output / From: CH647866 		- 1 Enquire
7890C LR003132
HOSE - OIL COOLER
Radiator To Cooler 		- 1 Enquire
