Name: Heat Shields - Exhaust System (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001)
Rating: 4.9 (1 reviews)

Heat Shields - Exhaust System (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001) of Land Rover Land Rover Discovery 4 (2010-2016) [4.0 Petrol V6]

View All

Land Rover Discovery 4 (2010-2016) [4.0 Petrol V6] - Heat Shields - Exhaust System (Cologne V6 4.0 EFI (SOHC)) ((V) FROMAA000001)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	KYG500380	SCREW AND WASHER - HEX HEAD	$0.35	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	WYH500050	NUT - LOCKING	$2.57	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	AYH100790	NUT - SPECIAL	$1.19	To Order

Photo	Part No	Description	Price (each)	Stock
	LR013545	SHIELD - EXHAUST PIPE	$91.10	To Order
	LR069248	SHIELD - EXHAUST PIPE	$61.87	To Order

Photo	Part No	Description	Price (each)	Stock
	LR013150	SHIELD	$91.10	To Order

Photo	Part No	Description	Price (each)	Stock
	WEB500144	HEAT SHIELD	$88.14	To Order

Photo	Part No	Description	Price (each)	Stock
	WEB500750	HEAT SHIELD	$160.37	To Order
	LR020125	HEAT SHIELD - EXHAUST	$160.37	To Order
	LR043377	HEAT SHIELD - EXHAUST	$158.51	To Order

...and 4 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	WEB000493	HEAT SHIELD	$104.06	To Order

Photo	Part No	Description	Price (each)	Stock
	WEB000483	HEAT SHIELD	$104.06	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HB1	KYG500380	SCREW AND WASHER - HEX HEAD IN STOCK	KYG500380 SCREW AND WASHER - HEX HEAD M6 X 16MM / From: AA000001 IN STOCK	$0.35	3
HN1	WYH500050	NUT - LOCKING IN STOCK	WYH500050 NUT - LOCKING M5 / From: AA000001 IN STOCK	$2.57	25
HN2	AYH100790	NUT - SPECIAL	AYH100790 NUT - SPECIAL M6 X 0.5-4, Nut "U" Spring / From: AA000001	$1.19	3
5E258A	LR013545	SHIELD - EXHAUST PIPE	LR013545 SHIELD - EXHAUST PIPE LH, Front, Lower / From: AA000001 / To: FA999999	$91.10	1
5E258A	LR069248	SHIELD - EXHAUST PIPE	LR069248 SHIELD - EXHAUST PIPE LH, Front, Lower / From: GA000001	$61.87	1
5E258B	LR013150	SHIELD	LR013150 SHIELD RH, Front, Lower / From: AA000001	$91.10	1
5K286A	WEB500144	HEAT SHIELD	WEB500144 HEAT SHIELD Centre / From: AA000001	$88.14	1
5K286B	WEB500750	HEAT SHIELD	WEB500750 HEAT SHIELD Intermediate / From: AA000001 / To: AA522702	$160.37	1
5K286B	LR020125	HEAT SHIELD - EXHAUST	LR020125 HEAT SHIELD - EXHAUST Intermediate / From: AA522703 / To: CA620737	$160.37	1
5K286B	LR043377	HEAT SHIELD - EXHAUST	LR043377 HEAT SHIELD - EXHAUST Intermediate / From: CA620738 / To: CA999999	$158.51	1
5K286B	LR076832	HEAT SHIELD - EXHAUST IN STOCK	LR076832 HEAT SHIELD - EXHAUST Intermediate / From: DA000001 / To: EA709728 IN STOCK	$94.64	1
5K286B	LR060755	HEAT SHIELD - EXHAUST	LR060755 HEAT SHIELD - EXHAUST Intermediate / From: EA709729 / To: FA765645	$87.20	1
5K286B	LR076832	HEAT SHIELD - EXHAUST IN STOCK	LR076832 HEAT SHIELD - EXHAUST Intermediate / From: FA765646 / To: FA999999 IN STOCK	$94.64	1
5K286B	LR069247	SHIELD - EXHAUST MANIFOLD HEAT	LR069247 SHIELD - EXHAUST MANIFOLD HEAT Intermediate / From: GA000001	$91.66	1
5K286C	WEB000493	HEAT SHIELD	WEB000493 HEAT SHIELD Rear LH / From: AA000001	$104.06	1
5K286D	WEB000483	HEAT SHIELD	WEB000483 HEAT SHIELD Rear RH / From: AA000001	$104.06	1
