Find Your Part

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR071842	SCREW AND WASHER - HEX HEAD	$1.28	To Order

Photo	Part No	Description	Price (each)	Stock
	LR121739	STUD - BALL	$3.20	To Order

Photo	Part No	Description	Price (each)	Stock
	LR146548	HOSE - COMPRESSED AIR	$58.32	To Order

Photo	Part No	Description	Price (each)	Stock
	LR125603	BRACKET - CHARGE AIR COOLER	$44.61	To Order

Photo	Part No	Description	Price (each)	Stock
	LR125605	TUBE - OUTLET	$91.64	To Order

Photo	Part No	Description	Price (each)	Stock
	LR125340	HEAT SHIELD - TURBOCHARGER	$25.30	To Order

Photo	Part No	Description	Price (each)	Stock
	LR146547	COOLER - ENGINE CHARGE AIR	$499.45	To Order

Photo	Part No	Description	Price (each)	Stock
	LR071745	SENSOR - AIR CHARGE TEMPERATURE	$46.63	To Order

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
HS1	LR071842	SCREW AND WASHER - HEX HEAD	LR071842 SCREW AND WASHER - HEX HEAD Hexagonal Head, M6 X 25MM / From: M2000001	$1.28	1
6A957	LR121739	STUD - BALL	LR121739 STUD - BALL Intercooler, M6 / From: M2000001	$3.20	4
6K770	LR146548	HOSE - COMPRESSED AIR	LR146548 HOSE - COMPRESSED AIR Outlet / From: M2000001	$58.32	1
6K864	LR125603	BRACKET - CHARGE AIR COOLER	LR125603 BRACKET - CHARGE AIR COOLER From: M2000001	$44.61	1
6N650	LR125605	TUBE - OUTLET	LR125605 TUBE - OUTLET Inlet / From: M2000001	$91.64	1
9A397	LR125340	HEAT SHIELD - TURBOCHARGER	LR125340 HEAT SHIELD - TURBOCHARGER Intercooler / From: M2000001	$25.30	1
9L440	LR146547	COOLER - ENGINE CHARGE AIR	LR146547 COOLER - ENGINE CHARGE AIR From: M2000001	$499.45	1
12A697	LR071745	SENSOR - AIR CHARGE TEMPERATURE	LR071745 SENSOR - AIR CHARGE TEMPERATURE From: M2000001	$46.63	1

Haven't found what you're looking for?

View Cart / Checkout

Intercooler/Air Ducts And Hoses (Nitra Plant Build) (3.0L Aj20D6 Diesel High) ((V) Fromm2000001)

Land Rover Defender (2020+) [3.0 I6 Turbo Diesel AJ20D6]
