Name: Air Suspension Compressor And Lines (Compressor Assy) (With Four Corner Air Suspension, Less Electric Engine Battery, Electric Engine Battery-MHEV)
Rating: 5.0 (1 reviews)

Air Suspension Compressor And Lines (Compressor Assy) (With Four Corner Air Suspension, Less Electric Engine Battery, Electric Engine Battery-MHEV) of Land Rover Land Rover Defender (2020+) [2.0 Turbo Petrol AJ200P]

View All

Land Rover Defender (2020+) [2.0 Turbo Petrol AJ200P] - Air Suspension Compressor And Lines (Compressor Assy) (With Four Corner Air Suspension, Less...

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR030752	BOLT AND WASHER - HEX.HEAD	$1.19	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR085629	CLIP - DOUBLE	$1.67	To Order

Photo	Part No	Description	Price (each)	Stock
	LR083989	CONNECTOR - VALVE BLOCK TO PIPE	$21.58	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	FY106046	NUT - HEX.	$0.69	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	LR140035	EXPANSION CHAMBER	$44.94	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	LR129144	TUBE - AIR SUSPENSION	$124.71	To Order
	LR163789	TUBE - AIR SUSPENSION	$125.18	To Order

Photo	Part No	Description	Price (each)	Stock
	LR095837	WIRE - AIR COMPRESSOR	$104.60	To Order

Photo	Part No	Description	Price (each)	Stock
	LR140034	COMPRESSOR - SUSPENSION LEVELLING	$1,234.87	To Order

Photo	Part No	Description	Price (each)	Stock
	LR095838	COMPRESSOR - SUSPENSION LEVELLING	$1,227.57	To Order

Photo	Part No	Description	Price (each)	Stock
	LR133506	PAD - FOAM	$56.05	To Order
	LR129152	PAD - INSULATING	$67.16	To Order

Photo	Part No	Description	Price (each)	Stock
	LR146170	VALVE - SOLENOID	$47.31	To Order

Photo	Part No	Description	Price (each)	Stock
	LR145373	SEAL	$6.36	To Order

Photo	Part No	Description	Price (each)	Stock
	LR098840	BRACKET - COMPRESSOR	$7.83	To Order

Photo	Part No	Description	Price (each)	Stock
	LR098841	BRACKET - COMPRESSOR	$7.83	To Order

Photo	Part No	Description	Price (each)	Stock
	LR130626	BRACKET - COMPRESSOR	$47.12	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
<021A32	LR145373	SEAL	LR145373 SEAL	$6.36	1
<31314	LR133506	PAD - FOAM	LR133506 PAD - FOAM Cover / To: M2036049	$56.05	1
<31314	LR129152	PAD - INSULATING	LR129152 PAD - INSULATING Cover / From: M2036050	$67.16	1
HB1	LR030752	BOLT AND WASHER - HEX.HEAD IN STOCK	LR030752 BOLT AND WASHER - HEX.HEAD Hexagonal Head, M6 x 22MM IN STOCK	$1.19	3
HC1	LR085629	CLIP - DOUBLE	LR085629 CLIP - DOUBLE 8 x 6MM, Single	$1.67	2
HM1	LR083989	CONNECTOR - VALVE BLOCK TO PIPE IN STOCK	LR083989 CONNECTOR - VALVE BLOCK TO PIPE Air Tube Connector, In Line IN STOCK	$21.58	1
HN1	FY106046	NUT - HEX. IN STOCK	FY106046 NUT - HEX. Hexagonal Head, M6 IN STOCK	$0.69	7
14A606	LR146170	VALVE - SOLENOID	LR146170 VALVE - SOLENOID	$47.31	1
19D625A	LR098840	BRACKET - COMPRESSOR	LR098840 BRACKET - COMPRESSOR Left Side	$7.83	1
19D625B	LR098841	BRACKET - COMPRESSOR	LR098841 BRACKET - COMPRESSOR Right Side	$7.83	1
19D625C	LR130626	BRACKET - COMPRESSOR	LR130626 BRACKET - COMPRESSOR Bottom	$47.12	1
2510	LR140035	EXPANSION CHAMBER ARRIVING SOON	LR140035 EXPANSION CHAMBER Air Suspension Lines ARRIVING SOON	$44.94	1
5319A	LR140034	COMPRESSOR - SUSPENSION LEVELLING	LR140034 COMPRESSOR - SUSPENSION LEVELLING Compressor Assy	$1,234.87	1
5319B	LR095838	COMPRESSOR - SUSPENSION LEVELLING	LR095838 COMPRESSOR - SUSPENSION LEVELLING Compressor Only, Includes Rivets And Label	$1,227.57	1
5637	LR129144	TUBE - AIR SUSPENSION	LR129144 TUBE - AIR SUSPENSION Short Wheelbase	$124.71	1
5637	LR163789	TUBE - AIR SUSPENSION	LR163789 TUBE - AIR SUSPENSION Long Wheelbase / From: P2000001	$125.18	1
14516	LR095837	WIRE - AIR COMPRESSOR	LR095837 WIRE - AIR COMPRESSOR	$104.60	1
