Front Seat Back (Side Seats) (Short Wheelbase) of Land Rover Land Rover Defender (2020+) [2.0 Turbo Diesel]

View All

Land Rover Defender (2020+) [2.0 Turbo Diesel] - Front Seat Back (Side Seats) (Short Wheelbase)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	LR039503	BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR093561	BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR096817	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR138647	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR118864	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR133016	PLUG - LEVER	Enquire	To Order
	LR133019	PLUG - LEVER	Enquire	To Order
	LR133019	PLUG - LEVER	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR132919	BEZEL - SCREEN MOULDING	Enquire	To Order
	LR132920	BEZEL - SCREEN MOULDING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR132861	BRACKET - SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR132939	LEVER - FRONT SEAT FOLDING	Enquire	To Order
	LR132941	SWITCH - RELAY	Enquire	To Order
	LR165918	SWITCH - RELAY	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR140457	FRAME - SEAT	Enquire	To Order
	LR146875	FRAME - SEAT	Enquire	To Order
	LR129420	FRAME - SEAT	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR130576	HOLDER - IPAD	Enquire	To Order
	LR129748	HOLDER - IPAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR080795	SUPPORT - FRONT SEAT SQUAB	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR109372	CAP - SCREW	Enquire	To Order
	LR109372	CAP - SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR132400	SUPPORT - SEAT BACK - LUMBAR	Enquire	To Order
	LR132399	SUPPORT - SEAT BACK - LUMBAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR036088	TENSIONER - SEAT RECLINE CABLE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR144650	MASS DAMPER - SEAT FRAME	Enquire	To Order
	LR144653	MASS DAMPER - SEAT FRAME	Enquire	To Order
	LR144650	MASS DAMPER - SEAT FRAME	Enquire	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR154977	MOTOR - SEAT ADJUSTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR132331	LEVER - SEAT ADJUSTER	Enquire	To Order
	LR132332	LEVER - SEAT ADJUSTER	Enquire	To Order
	LR132334	LEVER - SEAT ADJUSTER	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	LR074733	BRACKET - FRONT SEAT BACK FRAME	Enquire	To Order
	LR074734	BRACKET - FRONT SEAT BACK FRAME	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR074206	SLEEVE - HEADREST GUIDE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR133104	CARRIER - SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR098715	SUPPORT - SEAT BACK - LUMBAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	LR080793	SUPPORT - SEAT BACK - LUMBAR	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
<265A38	LR036088	TENSIONER - SEAT RECLINE CABLE	LR036088 TENSIONER - SEAT RECLINE CABLE Seat Recline, Tensioner	-	4	Enquire
<404C26	LR144650	MASS DAMPER - SEAT FRAME	LR144650 MASS DAMPER - SEAT FRAME Map Pocket - Mounted / To: L2999999	-	1	Enquire
<404C26	LR144653	MASS DAMPER - SEAT FRAME	LR144653 MASS DAMPER - SEAT FRAME Taurus Leather/Robust Woven Textile, Version - Commercial / From: M2000001 / To: M2055578	-	1	Enquire
<404C26	LR144650	MASS DAMPER - SEAT FRAME	LR144650 MASS DAMPER - SEAT FRAME Map Pocket - Mounted, Version - X-Dynamic / From: M2000001 / To: M2055578	-	1	Enquire
<404C26	LR155656	MASS DAMPER - SEAT FRAME	LR155656 MASS DAMPER - SEAT FRAME Map Pocket - Mounted, Version - X / From: M2055579	-	1	Enquire
<404C26	LR155657	MASS DAMPER - SEAT FRAME	LR155657 MASS DAMPER - SEAT FRAME Version - Commercial, Windsor Perforated/Windsor/Windsor / From: M2055579 / To: N2999999	-	1	Enquire
<404C26	LR155656	MASS DAMPER - SEAT FRAME	LR155656 MASS DAMPER - SEAT FRAME PVU Perforated, Version - Commercial, Windsor Perforated/Windsor/Windsor / From: P2000001	-	1	Enquire
<600E22	LR154977	MOTOR - SEAT ADJUSTER	LR154977 MOTOR - SEAT ADJUSTER RH/LH, Squab Recliner, Square Shaft / To: M2037446	-	1	Enquire
<611A99	LR132331	LEVER - SEAT ADJUSTER	LR132331 LEVER - SEAT ADJUSTER Acorn, Version - First Edition / RH, Seat Recline / To: M2060919	-	1	Enquire
<611A99	LR132332	LEVER - SEAT ADJUSTER	LR132332 LEVER - SEAT ADJUSTER Ebony/Vintage Tan, Version - X-Dynamic / RH, Seat Recline / To: M2048270	-	1	Enquire
<611A99	LR132334	LEVER - SEAT ADJUSTER	LR132334 LEVER - SEAT ADJUSTER Acorn, Version - Core / LH, Seat Recline / To: M2060919	-	1	Enquire
<611A99	LR132335	LEVER - SEAT ADJUSTER	LR132335 LEVER - SEAT ADJUSTER Ebony Black/Ebony Black Interior, Version - X-Dynamic / LH, Seat Recline / To: M2048270	-	1	Enquire
<611A99	LR154137	LEVER - SEAT ADJUSTER	LR154137 LEVER - SEAT ADJUSTER Acorn/Lunar, Version - X / RH, Seat Recline / From: M2060920	-	1	Enquire
<611A99	LR154138	LEVER - SEAT ADJUSTER	LR154138 LEVER - SEAT ADJUSTER Ebony Black/Ebony Black Interior, Version - X / RH, Seat Recline / From: M2048271	-	1	Enquire
<611A99	LR154135	LEVER - SEAT ADJUSTER	LR154135 LEVER - SEAT ADJUSTER Acorn/Lunar, Version - First Edition / LH, Seat Recline / From: M2060920	-	1	Enquire
<611A99	LR154136	LEVER - SEAT ADJUSTER	LR154136 LEVER - SEAT ADJUSTER Ebony/Vintage Tan, Version - X-Dynamic / LH, Seat Recline / From: M2048271	-	1	Enquire
<611D27	LR074733	BRACKET - FRONT SEAT BACK FRAME	LR074733 BRACKET - FRONT SEAT BACK FRAME Version - Commercial / RH / From: M2000001	-	1	Enquire
<611D27	LR074734	BRACKET - FRONT SEAT BACK FRAME	LR074734 BRACKET - FRONT SEAT BACK FRAME Version - Commercial / LH / From: M2000001	-	1	Enquire
<613K38	LR074206	SLEEVE - HEADREST GUIDE	LR074206 SLEEVE - HEADREST GUIDE	-	4	Enquire
<617D60	LR133104	CARRIER - SWITCH	LR133104 CARRIER - SWITCH Seat Cushion Power Fore/Aft, Seat Cushion Power Height / RH/LH	-	2	Enquire
<04487	LR133016	PLUG - LEVER	LR133016 PLUG - LEVER Acorn, Seat Cushion Manual Fore/Aft, Seat Cushion Manual Height / RH/LH / To: L2999999	-	2	Enquire
<04487	LR133019	PLUG - LEVER	LR133019 PLUG - LEVER Ebony/Vintage Tan, Seat Cushion Manual Fore/Aft, Seat Cushion Manual Height / RH/LH / To: L2999999	-	2	Enquire
<04487	LR133019	PLUG - LEVER	LR133019 PLUG - LEVER Khaki, Seat Cushion Manual Fore/Aft, Seat Cushion Manual Height, Version - X / RH/LH / From: M2000001	-	2	Enquire
<04487	LR133016	PLUG - LEVER	LR133016 PLUG - LEVER Acorn, Seat Cushion Manual Fore/Aft, Seat Cushion Manual Height, Version - Core / RH/LH / From: M2000001	-	2	Enquire
<06250	LR132919	BEZEL - SCREEN MOULDING	LR132919 BEZEL - SCREEN MOULDING Acorn, RSE System - Intergrated Tablet / RH/LH	-	2	Enquire
<06250	LR132920	BEZEL - SCREEN MOULDING	LR132920 BEZEL - SCREEN MOULDING Ebony/Vintage Tan, RSE System - Intergrated Tablet / RH/LH	-	2	Enquire
<52166	LR132861	BRACKET - SUPPORT	LR132861 BRACKET - SUPPORT RSE System - Intergrated Tablet / RH/LH	-	2	Enquire
<60252	LR132939	LEVER - FRONT SEAT FOLDING	LR132939 LEVER - FRONT SEAT FOLDING RH, Seat Recline / To: P2114091	-	1	Enquire
<60252	LR132941	SWITCH - RELAY	LR132941 SWITCH - RELAY LH, Seat Recline / To: P2114091	-	1	Enquire
<60252	LR165918	SWITCH - RELAY	LR165918 SWITCH - RELAY LH, Seat Recline / From: P2114092	-	1	Enquire
<60252	LR165920	LEVER - FRONT SEAT FOLDING	LR165920 LEVER - FRONT SEAT FOLDING RH, Seat Recline / From: P2114092	-	1	Enquire
<61018	LR140457	FRAME - SEAT	LR140457 FRAME - SEAT Driver/Pass Elec Fr Seat Adj/Memory / RH/LH / To: M2037446	-	2	Enquire
<61018	LR146875	FRAME - SEAT	LR146875 FRAME - SEAT Driver/Pass Elec Fr Seat Adj/Memory / Please Consider Repair Using Repair Component LR154977, RH/LH / From: M2037447	-	2	Enquire
<61018	LR129420	FRAME - SEAT	LR129420 FRAME - SEAT Less Seat Adjuster / Please Consider Repair Using Repair Component LR154977, RH/LH / To: P2109310	-	2	Enquire
<61018	LR174232	Frame	LR174232 Frame Less Seat Adjuster / Please Consider Repair Using Repair Component LR154977, RH/LH / From: P2109311	-	2	Enquire
<61028	LR130576	HOLDER - IPAD	LR130576 HOLDER - IPAD Acorn, RSE System - Intergrated Tablet / RH/LH	-	2	Enquire
<61028	LR129748	HOLDER - IPAD	LR129748 HOLDER - IPAD Khaki, RSE System - Intergrated Tablet / RH/LH	-	2	Enquire
<62400	LR080795	SUPPORT - FRONT SEAT SQUAB	LR080795 SUPPORT - FRONT SEAT SQUAB Less Seat Lumbar / RH/LH	-	2	Enquire
<62516	LR109372	CAP - SCREW	LR109372 CAP - SCREW To: L2999999	-	4	Enquire
<62516	LR109372	CAP - SCREW	LR109372 CAP - SCREW Version - X-Dynamic / From: M2000001	-	4	Enquire
<62532	LR132400	SUPPORT - SEAT BACK - LUMBAR	LR132400 SUPPORT - SEAT BACK - LUMBAR Left Side Of Both Seats	-	2	Enquire
<62532	LR132399	SUPPORT - SEAT BACK - LUMBAR	LR132399 SUPPORT - SEAT BACK - LUMBAR Right Side Of Both Seats	-	2	Enquire
<65500A	LR098715	SUPPORT - SEAT BACK - LUMBAR	LR098715 SUPPORT - SEAT BACK - LUMBAR Less Front Seat Bolster, Seat Lumbar - 4 Way / RH/LH	-	2	Enquire
<65500B	LR080793	SUPPORT - SEAT BACK - LUMBAR	LR080793 SUPPORT - SEAT BACK - LUMBAR Front Seat Power Bolster, Seat Lumbar - 4 Way / RH/LH	-	2	Enquire
HB1	LR039503	BOLT	LR039503 BOLT M10 x 1.0, Squab To Cushion	-	8	Enquire
HB2	LR093561	BOLT	LR093561 BOLT M6x1x16	-	-	Enquire
HC1	LR096817	CLIP	LR096817 CLIP 7 x 12, Fir Tree Clip, Support	-	-	Enquire
HC2	LR138647	CLIP	LR138647 CLIP RSE System - Intergrated Tablet	-	4	Enquire
HS1	LR118864	SCREW	LR118864 SCREW RSE System - Intergrated Tablet / M6 X 16	-	2	Enquire
